[SPARK-26260][Core]For disk store tasks summary table should show only successful tasks summary #26508

shahidki31 · 2019-11-13T22:16:28Z

…sks metrics for disk store

What changes were proposed in this pull request?

After #23088 task Summary table in the stage page shows successful tasks metrics for lnMemory store. In this PR, it added for disk store also.

Why are the changes needed?

Now both InMemory and disk store will be consistent in showing the task summary table in the UI, if there are non successful tasks

Does this PR introduce any user-facing change?

no

How was this patch tested?

Added UT. Manually verified

Test steps:

add the config in spark-defaults.conf -> spark.history.store.path /tmp/store
sbin/start-hitoryserver
bin/spark-shell
sc.parallelize(1 to 1000, 2).map(x => throw new Exception("fail")).count

…sks metrics for disk store

shahidki31 · 2019-11-13T22:20:14Z

cc @vanzin @srowen This PR is a followup for the PR #23088. Kindly review

core/src/main/scala/org/apache/spark/status/storeTypes.scala

core/src/main/scala/org/apache/spark/status/AppStatusStore.scala

SparkQA · 2019-11-14T00:07:42Z

Test build #113730 has finished for PR 26508 at commit df3e56b.

This patch fails Spark unit tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-14T01:24:33Z

Test build #113732 has finished for PR 26508 at commit 03304e1.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-14T19:43:18Z

Test build #113800 has finished for PR 26508 at commit a5690f6.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

vanzin · 2019-11-15T21:43:54Z

So, to solve this problem, you're changing the format of the data on disk. That breaks backwards compatibility (you'll run into problems if you run with an old disk store). So you have to update AppStatusStore.CURRENT_VERSION.

Given that I don't see a way to fix this without changing the disk format, I wonder if there are better alternatives than basically doubling the amount of disk space needed to store metrics.

What if you use the same existing fields and indices, but record successful tasks with positive numbers, and in progress or failed tasks as negative? You need some slight adjustments (e.g. TaskDataWrapper.hasMetrics needs to be a field now instead of computed from metrics, you need to use math.abs when returning metrics, etc), but wouldn't it result in the same thing?

shahidki31 · 2019-11-16T07:48:32Z

Thanks @vanzin for the input. Let me check and update.

SparkQA · 2019-11-16T18:48:48Z

Test build #113942 has finished for PR 26508 at commit f7a15d6.

This patch fails Scala style tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-16T18:56:36Z

Test build #113943 has finished for PR 26508 at commit c8196b8.

This patch fails Scala style tests.
This patch merges cleanly.
This patch adds no public classes.

shahidki31 · 2019-11-16T19:36:15Z

What if you use the same existing fields and indices, but record successful tasks with positive numbers, and in progress or failed tasks as negative? You need some slight adjustments (e.g. TaskDataWrapper.hasMetrics needs to be a field now instead of computed from metrics, you need to use math.abs when returning metrics, etc), but wouldn't it result in the same thing?

Thanks @vanzin , I have updated accordingly. It is working fine for both live and history UI

shahidki31 · 2019-11-16T19:40:35Z

I have tested manually also updated UT,

failed tasks
1 lac tasks per stage
bin/spark-shell
sc.parallelize(1 to 100000, 100000).count()

Time to load task page 1st time from InMemory ( for both Live and History UI) = ~9-10 sec
Time to load task page 1st time from DiskStore = ~ 14-15 sec

SparkQA · 2019-11-16T21:23:11Z

Test build #113944 has finished for PR 26508 at commit e8d0d14.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-16T22:24:09Z

Test build #113946 has finished for PR 26508 at commit b0988c3.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-16T22:46:09Z

Test build #113947 has finished for PR 26508 at commit 34420ea.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-17T16:56:09Z

Test build #113958 has finished for PR 26508 at commit f52eed8.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-17T17:49:47Z

Test build #113961 has finished for PR 26508 at commit af7244e.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

vanzin

Small test suggestion, otherwise looks ok.

core/src/main/scala/org/apache/spark/status/LiveEntity.scala

core/src/test/scala/org/apache/spark/status/AppStatusStoreSuite.scala

shahidki31 · 2019-11-21T04:45:42Z

@vanzin Is it ok to go in? Thanks

core/src/test/scala/org/apache/spark/status/AppStatusStoreSuite.scala

shahidki31 · 2019-11-22T11:25:58Z

Thanks @vanzin for the comments. I have updated accordingly

SparkQA · 2019-11-22T13:57:38Z

Test build #114295 has finished for PR 26508 at commit a8233dd.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-22T13:58:26Z

Test build #114294 has finished for PR 26508 at commit c5d76fd.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-22T16:14:47Z

Test build #114299 has finished for PR 26508 at commit d11859c.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-22T16:28:18Z

Test build #114302 has finished for PR 26508 at commit 07e4350.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

vanzin

Couple of small nits, then good to go.

core/src/test/scala/org/apache/spark/status/AppStatusStoreSuite.scala

core/src/main/scala/org/apache/spark/status/storeTypes.scala

SparkQA · 2019-11-23T14:39:17Z

Test build #114317 has finished for PR 26508 at commit 8c5a37d.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

SparkQA · 2019-11-23T14:44:55Z

Test build #114316 has finished for PR 26508 at commit 733b20e.

This patch passes all tests.
This patch merges cleanly.
This patch adds no public classes.

vanzin · 2019-11-25T18:03:53Z

Merging to master.

shahidki31 · 2019-11-25T18:25:28Z

Thanks a lot @vanzin , @srowen
