lenticular-fx

Animated lenticular print effect for React.
Two children, one wrapper. Slide the cursor and the back face restripes through interleaved vertical clip-path columns — exactly like a physical lenticular card.
Pure CSS clip-path, RAF-driven, optional 3D perspective tilt, zero runtime dependencies.

Live demo  ·  Install  ·  Quick start  ·  Examples  ·  API  ·  How it works

---

Why lenticular-fx?

🖼 Pure CSS clip-path	No canvas, no WebGL, no animation library. Just two stacked overlays cut into vertical strips by clip-path: path().
🎯 2–40 slices	Crank for fine-grain holographic feel or drop for chunky printed-card vibes. The slice maths are RAF-debounced and pixel-clean.
🌀 3D perspective tilt	Optional tilt prop applies a live rotateY driven by the same offset that scrubs the slicing — feels like dragging a real postcard.
📜 Scroll, gyroscope, cursor	Three input modes share one offset pipeline. scroll = page progress, gyroscope = device tilt, default = mouse.
🪟 Big hit area	hitMargin (default 24 px) pads the interaction zone so the cursor can overshoot the visible edge and still pin the back fully revealed.
🔌 Triggerable from parent	triggerParent listens on the wrapper's parent — the whole surrounding card becomes the hit target.
📦 Zero runtime deps	Just react and react-dom peer-deps. ~3 kB gzipped.
🟦 SSR-safe, fully typed	No window access at module level. First-class TypeScript types. Respects prefers-reduced-motion.

Installation

bun add lenticular-fx
# or
npm install lenticular-fx
# or
pnpm add lenticular-fx

Peer dependencies: react >= 18, react-dom >= 18.

Quick start

import { Lenticular } from 'lenticular-fx'

export function Card() {
  return (
    <Lenticular
      slices={12}
      front={<img src="/day.jpg" alt="Day" />}
      back={<img src="/night.jpg" alt="Night" />}
    />
  )
}

That's the whole API. Move the cursor across the wrapper and the back face restripes into view through interleaved vertical columns. Zero config beyond the two children.

Examples

// Card — product to specs
<Lenticular slices={10} ease={0.12}
  front={<ProductFront />}
  back={<ProductSpecs />}
/>

// Avatar — fine grain, slow lerp
<Lenticular slices={20} ease={0.08}
  front={<DayFace />}
  back={<NightFace />}
/>

// CTA — small element, chunky slices
<Lenticular slices={6} ease={0.18}
  front={<button>Get started →</button>}
  back={<button>Free for 14 days →</button>}
/>

// 3D perspective tilt — card follows cursor while slicing
<Lenticular slices={18} ease={0.12} tilt={14} hitMargin={40}
  front={<DayPostcard />}
  back={<NightPostcard />}
/>

// Track the cursor across the whole page
<Lenticular trackWindow slices={20}
  front={<Day />} back={<Night />}
/>

// Scroll-driven — offset follows viewport progress
<Lenticular scroll slices={14}
  front={<Hero variant="a" />} back={<Hero variant="b" />}
/>

// Instant snap, no lerp
<Lenticular slices={2} ease={1}
  front={<Before />} back={<After />}
/>

// Drive external UI from the offset (use a ref, not setState)
const barRef = useRef<HTMLDivElement>(null)

<Lenticular
  onOffsetChange={(o) => {
    if (barRef.current) barRef.current.style.width = `${o * 100}%`
  }}
  front={<Front />}
  back={<Back />}
/>

API reference

<Lenticular> is the only export. All standard HTMLDivElement attributes are forwarded to the wrapper. ref resolves to the wrapper <div>.

Prop	Type	Default	Description
front	ReactNode	required	Content shown when the cursor is on the left edge (offset = 0).
back	ReactNode	required	Content shown when the cursor is on the right edge (offset = 1).
slices	number	10	Number of interleaved vertical columns. Clamped to [2, 40].
ease	number	0.12	Lerp factor applied each animation frame. 1 = instant, 0.01 = molasses. Clamped to (0, 1].
defaultSide	'front' | 'back'	'front'	Which face shows at rest, before any interaction and after the cursor leaves.
trackWindow	boolean	false	Track the cursor across the whole viewport. X is still normalized to the wrapper.
hitMargin	number	24	Extra hit-area in px on every side of the wrapper. Lets the cursor overshoot the visible edge and still pin the back fully revealed. Set 0 to disable.
triggerParent	boolean	false	Listen on the wrapper's parent element. Cursor X is normalized to the parent's bounds — the whole surrounding card becomes the hit target.
scroll	boolean	false	Drive offset from the element's scroll progress through the viewport instead of the cursor.
tilt	number	0	3D perspective tilt in degrees, driven by the same offset. 0 disables. Typical 6–20.
perspective	number	900	CSS perspective in pixels used for the tilt. Lower = stronger 3D effect. Only applied when tilt > 0.
gyroscope	boolean	false	Use deviceorientation gamma (-45° → +45°) instead of mouse, on supported devices. Falls back to mouse if DeviceOrientationEvent is missing.
paused	boolean	false	Freeze the animation loop on the current frame.
onOffsetChange	(offset: number) => void	—	Called each animation frame with the current lerped offset (0 → 1). Use a ref — never call setState in this.
className	string	—	Extra class names applied to the wrapper <div>.
style	CSSProperties	—	Extra inline styles applied to the wrapper <div>.

How it works

The physical effect

A lenticular print is alternating vertical columns of two images placed behind a ribbed lens that redirects light by viewing angle — one eye sees columns from image A, the other from image B, and as you tilt the print the visible strips swap.

We simulate it with two stacked overlay layers above an invisible layout base, each cut to a set of vertical rectangles by clip-path: path().

The slice maths

slices = 10

Each slice is 1/slices wide (10% of the total width).
front  occupies odd  slices: 0%, 20%, 40%, 60%, 80%
back   occupies even slices: 10%, 30%, 50%, 70%, 90%

As --lenticular-offset goes 0 → 1, the clip-path boundaries
shift by one full slice width:
  offset = 0   → fully front
  offset = 0.5 → 50/50 mix
  offset = 1   → fully back

On every mousemove the cursor X is normalized to [0, 1] relative to the wrapper. A requestAnimationFrame loop lerps a currentOffset ref toward that target — React never re-renders inside the animation loop. Each frame we recompute two clip-path strings (one per layer) where each slice is a rectangle: the front layer's rectangle spans the left (1 − offset) of the slice, the back layer's the remaining right portion. When the stripes fill the slice or shrink below half a pixel we collapse to a single rectangle or hide entirely — that kills the sub-pixel anti-aliasing seams you would otherwise see at the extremes.

The infrastructure

• IntersectionObserver cancels the RAF when the element scrolls out of view; resumes on re-entry
• RAF-debounced ResizeObserver keeps the slice width in sync with layout changes — never caches dimensions at mount
• prefers-reduced-motion: reduce short-circuits the lerp to an instant snap
• hitMargin pads the invisible interaction zone (window-attached listener) so the cursor doesn't have to land on the exact visible edge
• Touch and deviceorientation (gamma → 0–1) feed the same target-offset pipeline as the mouse
• @property --lenticular-offset is registered for future styling hooks; the clip paths themselves are computed in JS each frame

Performance

• All animation state lives in refs — useRef for RAF id, current/target offset, observer instances. Zero setState calls in the loop.
• Style updates go straight onto element.style.setProperty / element.style.clipPath — never React-driven
• Off-screen instances cancel their RAF entirely via IntersectionObserver
• Overlay layers are pointer-events: none — the wrapped children stay fully clickable, focusable, selectable
• The base layer (visually invisible via opacity: 0) provides natural layout dimensions and is the accessible content seen by screen readers

Browser support

The effect relies on clip-path: path() with multiple sub-paths and the standard ResizeObserver / IntersectionObserver APIs.

• Chrome / Edge 88+
• Safari 14.1+ (incl. iOS Safari)
• Firefox 63+

SSR-safe — no window access at module level. The component renders a static placeholder (the front face fully visible) during SSR; listeners and the RAF loop only attach after hydration.

Demo

The live demo at lenticular.mvp-subha.me ships with:

• A global slices slider that updates every example live
• Card / avatar / CTA examples — the three "core" demos from the spec
• A 3D-perspective-tilt example showing tilt={14} with hitMargin={40}
• A playground with live controls for every prop and an auto-updating code snippet
• Gallery — album cover, trading card, number card, status pill, portrait, price tag, quote, ticker, mode toggle
• Dark / light theme toggle
• Full SEO / AEO meta stack — Open Graph, Twitter card, JSON-LD SoftwareSourceCode + FAQPage

Links

• 📦 npm — lenticular-fx
• 🌐 Demo — lenticular.mvp-subha.me
• 💻 GitHub — subhadeeproy3902/lenticular
• 🐦 Author — @mvp_Subha

Credits

Built by Subhadeep Roy with Claude — pair-programmed end-to-end, from the slice maths and the clip-path engine to the demo gallery, the 3D-tilt example, and the SEO/AEO wiring.

License

MIT © Subhadeep Roy
