This is a web component for displaying FIX (Financial Information eXchange) messages. It can render a FIX message as either a simple delimited string or a detailed, human-readable table.
The component parses FIX messages and enriches them with data from a FIX dictionary, providing tag names, value descriptions, and other useful information.
- Multiple Display Modes: View FIX messages as a raw string, a compact list, or a comprehensive HTML table.
- Hierarchical Group Display: Repeating groups are displayed in an indented, tree-like structure, making complex messages with nested components much easier to read.
- FIX Dictionary Support: Automatically uses the appropriate FIX dictionary based on the message version. It supports FIX versions 4.0 through 5.0 SP2.
- Checksum Validation: Automatically validates the message checksum and displays the result.
- Data Enrichment: Automatically describes values for common data types, including:
- Converting UTC and zoned timestamps to the user's local time.
- Displaying full names for currencies, countries, languages, and exchanges based on ISO standards.
- Customizable: Control the appearance and parsing with attributes like
message,delimiter, andmode. - Intelligent Version Detection: Automatically detects the data dictionary version from the message content when using FIXT 1.1.
- Color-Coded Data Types: The table view uses different colors for various data types (string, integer, float, etc.) to improve readability.
Demo FIX message decoder can be found here https://fix-decoder.samkov.ee
Watch a quick video tutorial on YouTube: https://youtu.be/Smyy3JWhHwc
To use the fix-message component, you need to include the fix-message.mjs script in your HTML file and then use the <fix-message> tag. The component will automatically render repeating groups in a tree-like structure.
<!DOCTYPE html>
<html>
<head>
<title>FIX Message Viewer</title>
<script type="module" src="src/fix-message.mjs"></script>
</head>
<body>
<h1>FIX Message Display</h1>
<fix-message
message="8=FIX.4.2|9=170|35=E|73=2|11=LIST1|55=EUR/USD|54=1|38=100|40=2|68=2|11=ORDER1|54=1|38=50|40=1|11=ORDER2|54=2|38=50|40=2|10=161"
mode="table"
delimiter="|"
></fix-message>
</body>
</html>message: The FIX message string to be displayed. The default delimiter is the SOH character (ASCII 1).delimiter: The delimiter used in themessagestring. The default is|.mode: The display mode. Can bestring,list,compact, ortable. If not specified, it will render as a string. Read more about modesdata-dictionary: (Optional) The path to a custom data dictionary XML file. If not provided, the component will use the built-in dictionaries based on the message'sBeginString(8)value. The format should be the same as the QuickFixJ XML dictionary format.use-host-dom: (Optional) If present, the component will render directly into the host element's DOM instead of its shadow DOM. This is useful for applying global styles.
If you don't specify a mode, the component will render the FIX message as a simple string with the specified delimiter. This is useful for quickly displaying the raw message. Read more about modes
<fix-message
message="8=FIX.4.2|9=123|35=D|..."
delimiter="|"
></fix-message>The list mode provides a simple, unstyled list of the FIX message's tag-value pairs, rendered using <ul> and <li> tags. This is useful for developers who want to apply their own custom styling. Read more about modes
<fix-message
message="8=FIX.4.2|9=123|35=D|..."
mode="list"
delimiter="|"
></fix-message>The compact mode is a space-saving alternative to the string mode. It replaces tag numbers with tag names and enum values with their corresponding value names. The message has visual formatting (coloring) and shows tooltips with descriptions. This mode is useful to save space when showing messages inline. Read more about modes
<fix-message
message="8=FIX.4.2|9=170|35=E|73=2|11=LIST1|...|68=2|11=ORDER1|...|11=ORDER2|...|10=161"
mode="compact"
delimiter="|"
></fix-message>The table mode provides a detailed, human-readable view of the FIX message, with each tag-value pair on its own row. This is ideal for analysis and debugging. Repeating groups will be automatically indented. Read more about modes
<fix-message
message="8=FIX.4.2|9=170|35=E|73=2|11=LIST1|...|68=2|11=ORDER1|...|11=ORDER2|...|10=161"
mode="table"
delimiter="|"
></fix-message>FIX messages often use the non-printable Start of Header (SOH) character (\x01) as a delimiter. You can pass the message in this format and the component will parse it correctly.
<fix-message
message="8=FIX.4.2�9=123�35=D�..."
mode="table"
></fix-message>For proprietary FIX implementations or custom tags, you can provide a path to your own dictionary file. This is useful when working with non-standard FIX messages. The dictionary file should be in the QuickFixJ XML format.
<fix-message
message="8=FIXT.1.1|9=123|35=W|...|9000=CUSTOM_VALUE"
mode="table"
delimiter="|"
data-dictionary="/path/to/your/custom-fix-dictionary.xml"
></fix-message>When using the default Shadow DOM encapsulation, you can customize the component's appearance by overriding its CSS custom properties.
<style>
fix-message {
--font-family: "Georgia", serif;
--tag-color: #9C27B0;
--string-value-color: #4CAF50;
--background-color: #222;
--font-color: #eee;
--border-color: #555;
--indent-step: 40px; /* Make indentation wider */
}
</style>See the example: blue style
Here is a list of the available CSS variables:
| Variable | Description | Default Value | Color |
|---|---|---|---|
--font-size |
The base font size for the table. | 14px |
|
--font-family |
The primary font for text content. | -apple-system, BlinkMacSystemFont, "Segoe UI", ... |
|
--font-monospace |
The font for monospace content like tags and values. | 'Consolas', 'Menlo', 'Courier New', monospace |
|
--indent-step |
The indentation width for each level in a nested group. | 25px |
|
--font-color |
The main text color. | #000E24 |
 |
--background-color |
The default background color. | #FFF |
 |
--even-backgroud-color |
The background color for even-numbered rows. | #E5F0FF |
 |
--header-font-color |
The font color for table headers. | #E5F0FF |
|
--header-background-color |
The background color for table headers. | #013A63 |
 |
--section-font-color |
The font color for section headers. | #E5F0FF |
|
--section-background-color |
The background color for section headers. | #66A3FF |
 |
--border-color |
The color for table borders. | #CCE0FF |
 |
--tree-color |
The color of the tree-like decorations for nested groups. | #cccccc |
 |
--tag-color |
The color for the tag number column. | #0366d6 |
 |
--string-value-color |
The color for string data types. | #269141 |
 |
--integer-value-color |
The color for integer data types. | #0366d6 |
|
--float-value-color |
The color for float/decimal data types. | #0366d6 |
|
--char-value-color |
The color for character data types. | #a61945 |
 |
--boolean-value-color |
The color for boolean data types. | #a61945 |
|
--datetime-value-color |
The color for date and time data types. | #a61945 |
|
--type-color |
The color for the data type column. | #999 |
 |
--value-color |
The default color for values in the table. | var(--font-color) |
|
If you want to apply your own global CSS styles to the component, you can use the use-host-dom attribute. This will render the component in the main document's DOM, allowing your stylesheets to apply. This is useful for integrating the component seamlessly into your application's design.
<style>
/* Example: Custom styles for the table */
fix-message table {
border: 2px solid blue;
}
</style>
<fix-message
message="8=FIX.4.2|9=123|35=D|..."
mode="table"
delimiter="|"
use-host-dom
></fix-message>See the example: Swedbank style
The fix-message component emits a rendered event after it has finished rendering the FIX message. This can be useful for performing actions after the component has been updated.
const fixMessageElement = document.querySelector('fix-message');
fixMessageElement.addEventListener('rendered', () => {
console.log('FIX message has been rendered.');
});The fix-message component also emits a copied event when the FIX message has been copied to the clipboard. This can be useful for displaying information about the copy-to-clipboard action to the user in your framework’s style.
const fixMessageElement = document.querySelector('fix-message');
fixMessageElement.addEventListener('copied', () => {
alert('FIX message has been copied to the clipboard.');
});The component uses several data modules to enrich the displayed FIX message. These modules are located in the src directory and can be customized if needed.
src/currencies.mjs: A list of currencies based on the ISO 4217 standard.src/countries.mjs: A list of countries based on the ISO 3166-1 standard.src/exchanges.mjs: A list of exchanges based on the ISO 10383 Market Identifier Code (MIC) standard.src/languages.mjs: A list of languages based on the ISO 639-1 standard.
This project is licensed under the MIT License. See the LICENSE file for details.
