This repository contains code and necessary files to generate Cascadia Subduction Zone interface geometries discretized into triangular elements based on depth contours or point clouds presented by four studies: 1) McCrory et al. (2012), 2) Hayes et al. (2018), 3) Sypus & Wang (2024), and 4) Bloch et al. (2023). In addition, there is code and input files to execute forward models with uniform or a Gaussian distribution of slip applied to subduction interface geometries, inversions of the latter, block models, and analysis of the results.
Codes are compatible with MATLAB and GNU Octave.
Dependent on:
- Gmsh v4.12.2 (Geuzaine & Remacle, 2009)
- tridisl (Loveless, 2021)
Apply uniform dip slip to an isolated subduction interface and calculate the resulting surface displacements.
Apply a Gaussian slip distribution (purely dip slip) to one interface, calculate displacements and invert those displacements onto a second interface.
Results from block models of Cascadia that use the block configuration and GNSS velocities from Saux et al. (2022). Models were ran using Blocks (Loveless et al., 2021).
Collection of codes to generate figures from Elston et al. (in review).
Collection of codes to generate a continuous mesh of triangular dislocation elements (TDEs) using depth contours at 5 km intervals down to 40 km depth. Each subdirectory contains the original contour or point cloud file(s) from its respective study, GMSH files containing depth contours only (.geo),GMSH files containing the discretized interface (.msh), and a .mat file compatible with other code in this repository. Four of the six subdirectories include files for an alternative geometry (under trenchAdded) that uses the USGS Cascadia trench coordinates as a 3.5 km depth contour. These geometries were used to run the aforementions block models.
blochC - Original point cloud: c_depth.nc
blocht - Original point cloud: t_depth.nc
mccrory - Original contours: Drafted_slab_contours_GC-S_WGS84.txt (hand drafted) and Modeled_slab_contours_GC-S_WGS84.txt (modeled)
slab2 - Original point cloud: cas_slab2_dep_02.24.18.txt
sypusAdjB - Original contours: AdjB_contours.txt
sypusGeometry - Original contours: Geometry_contours.txt
Collection of files needed to generate figures from Elston et al. (in review). Some colormaps are adapted from Crameri (2018).
Functions necessary to run codes using GNU Octave.
Bloch, W., Bostock, M. G., & Audet, P. (2023). A Cascadia Slab Model From Receiver Functions. Geochemistry, Geophysics, Geosystems, 24(10), e2023GC011088. https://doi.org/10.1029/2023GC011088
Crameri, F. (2018). Scientific colour-maps. Zenodo. http://doi.org/10.5281/zenodo.1243862
Geuzaine, C., & Remacle, J. (2009). Gmsh: A 3‐D finite element mesh generator with built‐in pre‐ and post‐processing facilities. International Journal for Numerical Methods in Engineering, 79(11), 1309–1331. https://doi.org/10.1002/nme.2579
Hayes, G. P., Moore, G. L., Portner, D. E., Hearne, M., Flamme, H., Furtney, M., & Smoczyk, G. M. (2018). Slab2, a comprehensive subduction zone geometry model. Science, 362(6410), 58–61. https://doi.org/10.1126/science.aat4723
Loveless, J. P. (2021). jploveless/tridisl: tridisl 1.0 (v1.0). Zenodo. https://doi.org/10.5281/zenodo.4622245
Loveless, J. P., Meade, B. J., & Evans, E. L. (2021). Blocks: Analysis of plate boundary deformation using geodetic data (Version 1.0) (v1.0). Zenodo. https://doi.org/10.5281/zenodo.4622191
McCrory, P. A., Blair, J. L., Waldhauser, F., & Oppenheimer, D. H. (2012). Juan de Fuca slab geometry and its relation to Wadati‐Benioff zone seismicity. Journal of Geophysical Research: Solid Earth, 117(B9), 2012JB009407. https://doi.org/10.1029/2012JB009407
Saux, J. P., Molitors Bergman, E. G., Evans, E. L., & Loveless, J. P. (2022). The Role of Slow Slip Events in the Cascadia Subduction Zone Earthquake Cycle. Journal of Geophysical Research: Solid Earth, 127(2), e2021JB022425. https://doi.org/10.1029/2021JB022425
Sypus, M., & Wang, K. (2024). Improved Cascadia Earthquake Source Models for Tsunami Hazard Assessment (No. OPEN-FILE REPORT O-24-11). DOGAMI. https://www.oregon.gov/dogami/pubs/pages/ofr/p-o-24-11.aspx
- Maintained by @helston
For bugs or questions, please open an issue.
|
|
This project is supported by the National Science Foundation through the Cascadia Region Earthquake Science Center (CRESCENT), Cooperative Agreement EAR-2225286.
