meshing

An interactive application for sculpting in 3D.

Distance functions defining the surface of a shape can be added additively and subtractively to form complex shapes. Functions are added to an octree which causes affected areas to be re-evaluated. Function evaluation consists of iterating over a hierarchical grid to find distances smaller than some threshold. Zero-crossing points are collected and uploaded to an openGL vertex buffer, then drawn.

Video

Controls:

Input	Action
Mouse movement	Look around
Left click	Add brush
Right click	Remove brush
1	Toggle shape
Up arrow	Increase brush size
Down arrow	Descrease brush size
Left arrow	Decrease blending
Right arrow	Increase blending
W	Move forward
S	Move backward
A	Move left
D	Move right
Left shift	Move down
Spacebar	Move up
E	Set light direction
NUM 7	Increase red
NUM 4	Decrease red
NUM 8	Increase green
NUM 5	Decrease green
NUM 9	Increase blue
NUM 6	Decrease blue
ESC	Close program

Dependencies:

• OpenGL 3.3
• glew
• glfw3
• glm
• c++11 compiler
• cmake

Building:

• mkdir build
• cd build
• cmake .. -G "your platform"
• cd ..
• cmake --build build --config Release

Running:

• cd bin
• ./main
