Snowflake Flow Diff for Apache NiFi

This action is brought to you by Snowflake, don't hesitate to visit our website and reach out to us if you have questions about this action.

Usage

When using the GitHub Flow Registry Client in NiFi to version control your flows, add the below file .github/workflows/flowdiff.yml to the repository into which flow definitions are versioned.

Whenever a pull request is opened, reopened or when a new commit is pushed to an existing pull request, this workflow will be triggered and will compare the modified flow(s) in the pull request and will automatically comment the pull request with a human readable description of the changes included in the pull request.

name: Snowflake Flow Diff on Pull Requests
on:
  pull_request:
    types: [opened, reopened, synchronize]

jobs:
  execute_flow_diff:
    runs-on: ubuntu-latest
    permissions:
      contents: read
      pull-requests: write
    name: Executing Flow Diff
    steps:
      # checking out the code of the pull request (merge commit - if the PR is mergeable)
      - name: Checkout PR code
        uses: actions/checkout@v4
        with:
          ref: ${{ github.event.pull_request.head.ref }}
          fetch-depth: 0
          path: submitted-changes

      # getting the path of the flow definition(s) that changed
      - name: Get changed files
        id: files
        run: |
          cd submitted-changes

          # 1. grab every changed connector JSON
          files=$(git diff --name-only $(git merge-base HEAD origin/${{ github.event.pull_request.base.ref }}) HEAD | grep '\.json$')

          # 2. make it a comma-separated list (no trailing comma)
          bare=$(echo "$files" | tr '\n' ',' | sed 's/,$//')

          # 3. prefix for original-code (flowA)
          flowA=$(echo "$bare" | sed 's|[^,]\+|original-code/&|g')

          # 4. prefix for submitted-changes (flowB)
          flowB=$(echo "$bare" | sed 's|[^,]\+|submitted-changes/&|g')

          # 5. export both as outputs
          echo "flowA=$flowA" >> $GITHUB_OUTPUT
          echo "flowB=$flowB" >> $GITHUB_OUTPUT

      # checking out the code without the change of the PR
      - name: Checkout original code
        uses: actions/checkout@v4
        with:
          fetch-depth: 2
          path: original-code
      - run: cd original-code && git checkout HEAD^

      # Running the diff
      - name: Snowflake Flow Diff
        uses: snowflake-labs/snowflake-flow-diff@v0
        id: flowdiff
        with:
          flowA: ${{ steps.files.outputs.flowA }}
          flowB: ${{ steps.files.outputs.flowB }}

Note - you may want to change grep '\.json$' with a more specific pattern to match your specific requirements.

Checkstyle

Optionally, it is possible to enable a checkstyle check on the new version of the flow. If some violations against NiFi best practices are found, a message will be added to the comment published on the pull request.

To enable checkstyle:

      # Running the diff
      - name: Snowflake Flow Diff
        uses: snowflake-labs/snowflake-flow-diff@v0
        id: flowdiff
        with:
          flowA: ${{ steps.files.outputs.flowA }}
          flowB: ${{ steps.files.outputs.flowB }}
          checkstyle: true
          # optional: path to YAML configuration of the rules
          checkstyle-rules: submitted-changes/.github/checkstyle/checkstyle-rules.yaml
          # optional: fail the action when violations are detected
          checkstyle-fail: true

If checkstyle-fail is set to true, the GitHub Action will exit with a non-zero status whenever checkstyle violations are detected, which ensures the workflow (and therefore the pull request) is blocked until the issues are fixed.

The YAML file can be used to include or exclude specific rules and to configure rule parameters. For example:

include:
  - concurrentTasks
rules:
  concurrentTasks:
    parameters:
      limit: 2
    overrides:
      ".*sql-connector":
        limit: 4
    exclude:
      - "Ignore.*"
    componentExclusions:
      "ProdFlow.*":
        - "1a59f65f-8b3a-3db9-982e-e0d334bd7e9c" # processor UUID to ignore

At the root level, if include is specified, only those rules will be executed. If exclude is specified AND include is not specified, all rules except the ones specified will be executed. For each rule, it is possible to specify default values for parameters (when supported by the rule, see below), to override parameters for specific flows using a regular expression against the flow name, to exclude flows using a regular expression, and to silence violations for specific component UUIDs via componentExclusions.

Component-level exclusions

Some rules (for example concurrentTasks, noSelfLoop, enforcePrioritizer, or backpressureThreshold) may need an exception for a single processor or connection while you keep the rule enabled for the rest of the flow. You can scope exclusions down to the UUID under the componentExclusions map, keyed by flow-name regular expressions:

include:
  - noSelfLoop
rules:
  noSelfLoop:
    componentExclusions:
      "ProductionFlow.*":
        - "2d8da922-fd1f-3519-9d54-6482dfd42c56"
      ".*": # optional global fallback
        - "50a3b081-d54d-3ad8-b74c-caa7fef59bb2"

When the flow name matches the regex, violations produced for the listed component IDs are ignored, while all other components continue to be checked normally. Use the same pattern for rules that operate on connections (for example enforcePrioritizer or backpressureThreshold) by listing the connection identifiers to suppress.

Rule identifiers and exclusion targets

The following table summarizes what each rule reports and which identifiers you can expect when configuring componentExclusions:

Rule id	Violation references	componentExclusions target
concurrentTasks	Processor name and UUID	Processor UUID (VersionedProcessor#getIdentifier)
snapshotMetadata	Flow name only	Not applicable
emptyParameter	Parameter name	Not applicable
defaultParameters	Parameter name	Not applicable
unusedParameter	Parameter name	Not applicable
noSelfLoop	Component name/type and UUID	Processor/Funnel UUID at both ends of the self-loop
enforcePrioritizer	Connection description and UUID	Connection UUID (VersionedConnection#getIdentifier)
backpressureThreshold	Connection description and UUID	Connection UUID (VersionedConnection#getIdentifier)

Available rules:

• concurrentTasks to check the number of concurrent tasks and define an upper limit (parameter: limit, default value is 2)
• snapshotMetadata to check that the flow snapshot metadata is present in the file
• emptyParameter to check that no parameter is set to an empty string
• defaultParameters to check parameters with a default value (parameter: defaultParameters, comma-separated list of parameter names having an expected default value)
• unusedParameter to check if all specified parameters are used in the flow
• noSelfLoop to check if there are self-loop connections in the flow
• enforcePrioritizer to check if all connections in the flow are set with the configured list of prioritizers (parameter: prioritizers, comma-separated list of expected prioritizers, example: org.apache.nifi.prioritizer.FirstInFirstOutPrioritizer)
• backpressureThreshold to ensure each connection keeps both data size and object count backpressure thresholds greater than zero

Example

The GitHub Action will automatically publish a comment on the pull request with a comprehensive description of the changes between the flows of the two branches. Here is an example of what the comment could look like:

### Executing Snowflake Flow Diff for flow: `MyExample`

#### Checkstyle Violations
> [!CAUTION]
> - Processor named `UpdateAttribute` is configured with 4 concurrent tasks

#### Flow Changes
- The destination of a connection has changed from `UpdateAttribute` to `InvokeHTTP`
- A self-loop connection `[success]` has been added on `UpdateAttribute`
- A connection `[success]` from `My Generate FlowFile Processor` to `UpdateAttribute` has been added
- A Processor of type `GenerateFlowFile` named `GenerateFlowFile` has been renamed from `GenerateFlowFile` to `My Generate FlowFile Processor`
- In Processor of type `GenerateFlowFile` named `GenerateFlowFile`, the Scheduling Strategy changed from `TIMER_DRIVEN` to `CRON_DRIVEN`
- A Parameter Context named `Test Parameter Context` has been added
- The Parameter Context `Test Parameter Context` with parameters `{addedParam=newValue}` has been added to the process group `TestingFlowDiff`
- A Processor of type `UpdateAttribute` named `UpdateAttribute` has been removed
- In Processor of type `GenerateFlowFile` named `GenerateFlowFile`, the Run Schedule changed from `1 min` to `* * * * * ?`
- A Parameter Context named `Another one to delete` has been added
- A Processor of type `UpdateAttribute` named `UpdateAttribute` has been added with the configuration [`ALL` nodes, `4` concurrent tasks, `0ms` run duration, `WARN` bulletin level, `TIMER_DRIVEN` (`0 sec`), `30 sec` penalty duration, `1 sec` yield duration] and the below properties:
  - `Store State` = `Do not store state`
  - `canonical-value-lookup-cache-size` = `100`

#### Bundle Changes
- The bundle `org.apache.nifi:nifi-standard-nar` has been changed from version `2.1.0` to version `2.2.0`
