Reference Standard M

---

ANSI/MDC Standard M X11.1-1995 (ISO/IEC 11756:1999)

Version 1.82.4 - 2024 Dec 9

Copyright and License

Developed and maintained by David Wicksell <dlw@linux.com>
Copyright © 2020-2024 Fourth Watch Software LC
https://gitlab.com/Reference-Standard-M/rsm

Originally based on MUMPS V1 by Raymond Douglas Newman
Copyright © 1999-2018
https://gitlab.com/Reference-Standard-M/mumpsv1

This program is free software: you can redistribute it and/or modify it under the terms of the GNU Affero General Public License (AGPL) as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Affero General Public License for more details.

You should have received a copy of the GNU Affero General Public License along with this program. If not, see https://www.gnu.org/licenses/.

Full license text: AGPL-3.0-or-later

Summary and Information

Reference Standard M (RSM) is an implementation of the M programming language and database, which implements the latest M standard that has been released by the M Development Committee (MDC), currently ANSI/MDC X11.1-1995 (ISO/IEC 11756:1999).

RSM was originally named MUMPS V1 (MV1), and was created by Raymond Douglas Newman. When I took over maintenance and development of MV1, I changed its name to better reflect its use as a reference implementation for the MDC.

See the Changelog for more information on the development of Reference Standard M. The RSM documentation is a work-in-progress. This software uses semantic versioning.

This is the post-relational database.

Installation

RSM builds and runs on most UNIX, and UNIX-derived platforms, running 32-bit and 64-bit processors, in little-endian and big-endian mode. The platforms that have been tested, and/or known (or suspected) to build and run RSM, are:

• Linux (Ubuntu, Debian, Red Hat, OpenSUSE, and Slackware) on i386 and x86_64

• Debian Linux on ppc64le

• Gentoo Linux on IA-64

• FreeBSD on amd64

• NetBSD on amd64

• OpenBSD on amd64

• macOS 10.4 and newer on ILP32 and LP64 Intel (Clang or GCC)

• macOS 11.0 and newer on 64-bit M1 ARMv8 (Clang or GCC)

• Solaris on i86pc and Sun-4v (SPARC)

• Tru64 on Alpha

• AIX on ppc32be and ppc64be

• HP-UX on IA-64

• Windows XP, 7, 10, and 11, under Cygwin

• Windows 10 and 11, under Windows Subsystem for Linux (WSL) 1 and 2

• Raspberry Pi on armv6l and armv7l running Raspbian

• Mobian (Mobile Debian Linux) on aarch64

Thanks to John Willis for providing access to the build farm, and to Matthew Wilson, Terry Wiechmann, and Flavio Fornazier for helping me with testing.

To build RSM, clone the RSM git repository:

$ git clone https://gitlab.com/Reference-Standard-M/rsm.git

Change to the rsm directory and build the rsm executable:

$ make

or

$ make -j

On Solaris:

$ gmake

or

$ gmake -j

The resulting rsm executable will be optimized for your system.

Install the rsm executable to the default bin directory [/usr/local/bin], and the utils.rsm utilities to the default rsm directory [/usr/local/share/rsm]:

$ sudo make install

Install the rsm executable to a different bin directory [/usr/bin], and the utils.rsm utilities to a different rsm directory [/usr/share/rsm]:

$ sudo make install prefix=/usr

On Cygwin (as administrator):

$ make install

Clean up the build environment after installation:

$ make clean

Uninstall the rsm executable from the default bin directory [/usr/local/bin], and the utils.rsm utilities from the default rsm directory [/usr/local/share/rsm]:

$ sudo make uninstall

Uninstall the rsm executable from a different bin directory [/usr/bin], and the utils.rsm utilities from a different rsm directory [/usr/share/rsm]:

$ sudo make uninstall prefix=/usr

Install the documentation (asciidoc/man page) to the default rsm and man1 directories [/usr/local/share/doc/rsm, /usr/local/share/man/man1]:

$ sudo make install-docs

Install the documentation (asciidoc/man page) to different rsm and man1 directories [/usr/share/doc/rsm, /usr/share/man/man1]:

$ sudo make install-docs prefix=/usr

On Cygwin (as administrator):

$ make install-docs

Note	On macOS and AIX, you might have to add the path that make install-docs installed the rsm man page in, to the MANPATH environment variable

Uninstall the documentation (asciidoc/man page) from the default rsm and man1 directories [/usr/local/share/doc/rsm, /usr/local/share/man/man1]:

$ sudo make uninstall-docs

Uninstall the documentation (asciidoc/man page) from different rsm and man1 directories [/usr/share/doc/rsm, /usr/share/man/man1]:

$ sudo make uninstall-docs prefix=/usr

Usage

Output a short version string:

$ rsm -V

Output a helpful options menu:

$ rsm -h

Note	Set the environment variable RSM_DBFILE to the database file path to avoid having to pass it to rsm

To use RSM, create a database:

# Optional arguments in square brackets
#  -v <volume-name>        Name of volume             (1-32 alpha characters)
#  -b <block-size>         Size of database blocks    (1-256 KiB)
#  -s <database-size>      Initial size of database   (100-2147483647 blocks)
# [-m <map-size>]          Size of map block          (0-262147 KiB)
# [-e <environment-name>]  Name of manager UCI        (1-32 alpha characters)
# [<database-file>]        Name of the database file

$ rsm -v TST -b 16 -s 4096 tst.dat

or

$ export RSM_DBFILE="/home/user/tst.dat"
$ rsm -v TST -b 16 -s 4096

Note	In order to load the supplied M utilities, use a block size of 14 KiB or larger

Initialize and start the environment:

# Optional arguments in square brackets
#  -j <max-jobs>          Size of job table in environment  (1-1024 jobs)
# [-g <global-buffers>]   Size of global buffers            (1-131072 MiB)
# [-r <routine-buffers>]  Size of routine buffers           (1-4095 MiB)
# [<database-file>]       Name of the database file

$ rsm -j 12 tst.dat

or

$ export RSM_DBFILE="/home/user/tst.dat"
$ rsm -j 12

On macOS, you might need to increase the accessible shared memory before starting the environment, if the previous command failed. If so, as root or using sudo, run the following commands, adjusted based on your system resources:

# 2 GiB shared segment max:
$ sudo sysctl -w kern.sysv.shmmax=2147483648

# 8 GiB of system shared memory (in number of pages at 4096 bytes per page):
$ sudo sysctl -w kern.sysv.shmall=2097152

To persist the above configuration changes on macOS, you’ll need to create a property list configuration and load it so the daemon picks it up at boot time. There is a sample plist XML file at rsm/etc/sysctl.plist. Run these commands, after adjusting the kern.sysv.shmmax and kern.sysv.shmall settings based on your system resources, and ensuring you aren’t overwriting an existing file with that name:

# Copy plist configuration to the correct system location
$ sudo cp /Users/user/rsm/etc/sysctl.plist /Library/LaunchDaemons/sysctl.plist

# Change its ownership
$ sudo chown root:wheel /Library/LaunchDaemons/sysctl.plist

# Load it for the launch daemon to run at boot
$ sudo launchctl load /Library/LaunchDaemons/sysctl.plist

On Cygwin, you need to configure and start cygserver (as administrator) before starting the RSM environment, as it provides the SysV shared memory support.

$ cygserver-config
$ cygrunsrv -S cygserver

Output a database and environment configuration:

$ rsm -i tst.dat

or

$ export RSM_DBFILE="/home/user/tst.dat"
$ rsm -i

Load the M utilities (using the bootstrap method):

# Optional arguments in square brackets
# -x <M-command(s)>        String of M commands to execute
# [-e <environment-name>]  Name of initial UCI environment
# [<database-file>]        Name of the database file

$ rsm -x 'open 1:("utils.rsm":"read") use 1 read code xecute code' tst.dat

or

$ export RSM_DBFILE="/home/user/tst.dat"
$ rsm -x 'open 1:("utils.rsm":"read") use 1 read code xecute code'

Start direct mode:

# Optional arguments in square brackets
# [-e <environment-name>]  Name of initial UCI environment
# [-R]                     Starts in restricted mode
# [<database-file>]        Name of the database file

$ rsm tst.dat

or

$ export RSM_DBFILE="/home/user/tst.dat"
$ rsm

Run an M routine in indirect mode:

# Start the M Command Language shell
# Optional arguments in square brackets
# -x <M-command(s)>        String of M commands to execute
# [-e <environment-name>]  Name of initial UCI environment
# [-R]                     Starts in restricted mode
# [<database-file>]        Name of the database file

$ rsm -x "do ^%M" tst.dat

or

$ export RSM_DBFILE="/home/user/tst.dat"
$ rsm -x "do ^%M"

When upgrading to a new version of RSM, you might occasionally run in to an issue executing a routine. Normally this will not be an issue, but if it is, you can fix it by recompiling the routines:

RSM [MGR,TST]> merge ^$routine("%RECOMP")=^$routine("%RECOMP")
RSM [MGR,TST]> do ^%RECOMP

Stop and shut down environment:

$ rsm -k tst.dat

or

$ export RSM_DBFILE="/home/user/tst.dat"
$ rsm -k

From within an RSM job:

RSM [MGR,TST]> kill ^$job

If utils.rsm has been loaded:

RSM [MGR,TST]> do ^SSD

Docker Container

To download the latest RSM Docker image from Docker Hub:

$ docker pull dlwicksell/rsm

To build the RSM Docker image from source, while in the rsm directory:

$ docker build -t rsm .

or

$ docker buildx build -t rsm .

You can change a few build parameters, by passing them as follows:

# Pass each build argument with a separate --build-arg  - as below
# journal=on       Turns journaling on in the image     - defaults to off
# bsize=<bsize>    The size of a database block in KiB  - defaults to 16
# blocks=<blocks>  The number of blocks in the database - defaults to 16384

$ docker build -t rsm \
      --build-arg journal=on \
      --build-arg bsize=32 \
      --build-arg blocks=32768 .

or

$ docker buildx build -t rsm \
      --build-arg journal=on \
      --build-arg bsize=32 \
      --build-arg blocks=32768 .

Note	If you build the image from source, using the previous example, replace dlwicksell/rsm with rsm below

To create and run the Docker container with RSM in direct mode:

$ docker run -it --rm --name rsm dlwicksell/rsm

or

$ docker run -it --name rsm dlwicksell/rsm

To create and run it in detached mode:

$ docker run -itd --name rsm dlwicksell/rsm

The RSM Docker container runs with port 80 open. To map an open port on your host machine to the container port (replace 8080 with an available local port):

$ docker run -itd --name rsm -p 8080:80 dlwicksell/rsm

You can change a few runtime parameters, by passing them as follows:

# The first argument [32|2] will set the number of maximum RSM jobs - default 12
# The second argument ['write...'] will run that M code and remove the container

$ docker run -it --rm --name rsm dlwicksell/rsm 32
$ docker run -it --rm --name rsm dlwicksell/rsm 2 'write $system,!'

To run RSM in direct mode while the container is in detached mode:

$ docker exec -it rsm rsm

To run RSM commands while the container is in detached mode:

$ docker exec -it rsm rsm -i
$ docker exec -it rsm rsm -h
$ docker exec -it rsm rsm -V
$ docker exec -it rsm rsm -x 'write $system,!'

To run the Bash shell while the container is in detached mode:

$ docker exec -it rsm bash

To start the container while in detached mode:

$ docker start rsm

To stop the container while in detached mode:

$ docker stop rsm

Consult the Docker documentation to learn about other ways you can run and manage the RSM Docker image and container.

Database Upgrade

Version 1.73.0 of RSM introduced a change from 8 character identifiers to 32 character identifiers. This necessitated a change to the database format, the routine bytecode format, and the journal format, which required bumping the database version from 1 to 2, the compiler version from 7 to 8, and the journal version from 1 to 2.

The RSM runtime image will detect a database in the older format, as well as compiled bytecode in the older format, and return an appropriate error. If you would like to move your globals and routines from an old database to a new one, which works with this version of RSM, please follow these database upgrade instructions, or run the upgrade script.

Enjoy!
