vibeX

Your architecture diagram is a lie.

vibeX reads the thing that can't lie — your Prisma schema, your OpenAPI document, your GraphQL SDL, or the source itself — and renders the diagram that's actually true. Then it documents the system in claims that fail CI when the code moves underneath them.

One standalone HTML file. No server. Nothing leaves your network.

---

The diagram you have right now

• a whiteboard photo in a Slack thread
• a Confluence page last touched in 2023
• a Miro board nobody can find
• a Mermaid block that stopped rendering
• the one guy who knows

→ one command, run against the schema that actually ships.

npx skills add Raja0sama/vibex -g -a claude-code -a codex -y   # Claude Code + Codex, then just ask
npx @vibex/vibex demo out                                      # or look first: installs nothing

Watch the demo

Why "vibeX"

vibe — how code gets written now. Fast, AI-assisted, more of it than anyone can hold in their head. X — the crossings. Which table joins which. Which service calls which. What happens after approval.

You vibed it into existence. vibeX shows you what you actually built.

The mark is the same idea: two edges crossing. Everything interesting in a system is a line between two things, not the things themselves.

Five diagrams. One source of truth.

	Type	What it draws	Import from
🔵	erd	tables, columns, PK/FK badges, crow's-foot cardinality that knows nullable from not, bounded contexts as groups	Prisma, GraphQL SDL (--erd)
🟣	c4	persons, systems, containers, components, databases, queues, each with its own fill, inside tinted nested boundaries	hand-authored
🟢	endpoints	REST routes, GraphQL operations, published events — grouped by resource, with method badges, auth, params, status codes	OpenAPI 2/3, GraphQL SDL
🟡	lifecycle	every state a thing can reach and every legal move between them, with actor, event, guard and side effect on each arrow	hand-authored
🔷	links	the System view: every call between services, pinned to the client that makes it and the handler that serves it, across repositories	hand-authored from clients and handlers

Each is a validated JSON spec plus a rendered viewer. The spec is the artifact you keep; the HTML is disposable. Documentation and changes are two more views over the same specs, all in one dashboard file. Every diagram also exports as Mermaid (vibex mermaid <spec>, or the button in the viewer) for Markdown that renders it.

Which service calls which. A *.links.json records each call once, anchored on both ends. vibex links checks it against the code:

vibex links system.links.json docs --repo bff=../bff --repo orders=../orders --check

It fails when a client or handler moved, an endpoint it names is gone, or a C4 arrow has no call behind it. It also lists endpoints nothing calls. In a monorepo, pass --repo ..

Three commands. No config file.

# 1. import — your schema becomes a draft spec
vibex import prisma  prisma/schema.prisma  docs/db.erd.json
vibex import openapi openapi.yaml          docs/api.endpoints.json
vibex import graphql schema.graphql        docs/api.endpoints.json

# 2. validate — dangling refs and unreachable states are errors that name the field
vibex validate docs/db.erd.json

# 3. render — one file, CSS and JS inlined, spec embedded
vibex render docs/db.erd.json --open
#    or --linked: the HTML is only a placeholder; data goes in db.erd.data.js
#    and the viewer in vibex-viewer.js/.css beside it (still opens from disk)

# every spec in the folder, one page, cross-linked
vibex dashboard docs/index.html docs --title "Payments platform" --repo .

No source schema? It reads the code — NestJS controllers, GraphQL resolvers, TypeORM entities, Express routers, SQL migrations — and writes the spec itself.

Install it as a skill and stop learning flags

vibeX is a Claude Code / Codex skill first and a CLI second. Installed as a skill, the whole command surface collapses into a sentence — the agent reads SKILL.md, finds your schema, picks the diagram type, writes the spec and renders it:

> show me the data model
  wrote db.erd.json · db.erd.html

> now the endpoints
  wrote api.endpoints.json · api.endpoints.html

> what happens after a request is approved?
  wrote request.lifecycle.json · request.lifecycle.html

> document the auth service and fail CI when it drifts
  wrote auth.docs.json · 41 claims, 38 verified

Install it. Pick your agent:

Agent	Command
Claude Code + Codex	npx skills add Raja0sama/vibex -g -a claude-code -a codex -y
Claude Code plugin	/plugin marketplace add Raja0sama/vibex, then /plugin install vibex@vibex
Codex, by hand	git clone https://github.com/Raja0sama/vibex ~/.agents/skills/vibex

Then:

1. Restart the agent (or open a new session).
2. Ask: "show me the data model".

-g installs for your user, so every project sees it. Codex reads ~/.agents/skills; Claude Code gets a symlink in ~/.claude/skills. The plugin route updates through /plugin instead.

Check it landed:

node ~/.agents/skills/vibex/bin/vibex.mjs types

Other ways in: per project, other agents, pinned to a release, or from source

Per project, so the skill is checked in beside the code it documents. Drop -g and run it inside the repo:

cd my-project && npx skills add Raja0sama/vibex -a claude-code -a codex -y

Another agent (Cursor, Gemini CLI, OpenCode, Copilot and more): swap the -a values, or run npx skills add Raja0sama/vibex and pick from the list.

Pinned to a published version. SKILL.md ships inside the npm package, so a global install plus one symlink does it:

npm i -g @vibex/vibex
ln -s "$(npm root -g)/@vibex/vibex" ~/.claude/skills/vibex   # or ~/.agents/skills/vibex for Codex

Under nvm, npm root -g is scoped to the Node version you are on. Install a new Node and both the vibex binary and this symlink stop resolving, silently. skills add has no such problem.

From source, if you are changing vibeX itself. The symlink tracks your working copy, so edits apply the moment you save:

git clone https://github.com/Raja0sama/vibex && cd vibex
ln -s "$(pwd)" ~/.claude/skills/vibex

skills add and the plugin clone the repository, not the npm package, so they have no node_modules. Run npm install inside the skill folder only if you need YAML OpenAPI. The npm paths already have it.

---

Prose that can't quietly go stale

An AI wrote the sentence once. Arithmetic checks it forever.

A diagram can't drift from the schema, because it's generated from it. Prose can, and always does. So vibex docs documents a system the same way it draws one — the unit isn't a page, it's a claim: one sentence with a source attached.

vibex docs system.docs.json specs/ --repo . --check   # exit 1 on any claim that no longer holds

There is no model in the verification path — only fs, path, crypto and git. That is the whole point, and it is why a full drift check costs ~70ms and nothing per run.

What it does not do

It catches drift, not initial error. If the first draft misreads the code, the hash still matches, CI stays green, and a wrong claim can stay verified indefinitely. Reviewing the spec once, at authoring time, is the only thing that establishes truth.

The honest version: you get a reviewable first draft in one pass, and after you have read it once, arithmetic keeps it honest.

How a claim works — three sources, five computed confidence states

Source	What holds it up
derived	Computed from a diagram spec by one of ten fixed generators. Cannot disagree with the diagram beside it, because it is the diagram.
anchored	Prose pinned to a file and a symbol by a content hash. In languages where whitespace is not syntax (TypeScript, JSON, Go, …) the hash ignores it — reformat the file and nothing moves; change the line and the claim flags itself. Everywhere else (Python, YAML, Makefiles, any unknown extension) indentation counts, and only trailing whitespace and line endings are ignored.
asserted	A person's decision, with their name and the date. For what no file can prove — and it expires, so "we decided this in March" can't pass for fact forever.

Confidence is computed, never written. A claim cannot declare how trustworthy it is. The build assigns one of five states from the evidence and the clock, and the validator rejects any claim that tries to rate itself:

verified · stated · needs re-reading · out of date · unverifiable

vibex docs system.docs.json specs/ --repo . --reanchor   # re-pin hashes after a deliberate edit
vibex docs system.docs.json specs/ --repo . --md doc.md  # portable Markdown, zero raw HTML

Incremental, keyed on git. docs.lock.json records the commit each claim last verified at, so a rebuild re-reads only what git says moved — and every uncertainty resolves toward reading more, never less. CI passes --no-lock: a lock file arrives from a contributor's machine asserting that claims were verified, and CI re-reads every anchor rather than taking that on trust.

It tells you what it doesn't cover. Every document renders three lists: what was read, what is deliberately out of scope and why, and what the build noticed but could not account for. A document that implies completeness gets believed exactly where it is wrong.

One artefact, two readers. People read the dashboard panel; agents read docs.json — every fact once, addressable, with resolved edges, so "what breaks if I change this" is a single lookup rather than a search. Narrative sections carry Markdown that cites claims inline with [[claim-id]], rendering each citation as a coloured pip showing that claim's confidence, so a reader sees which words are load-bearing.

One document per question. auth.docs.json, payments.docs.json — each becomes its own dashboard entry. Not one document trying to be the whole system.

Pass --repo to dashboard or every anchored claim renders as unverifiable.

Wrong? Fix it from where you found it — the intake loop

Every claim and node carries a report link. It opens an issue with a fenced vibex block naming exactly what the reader was looking at, so the request arrives with its coordinates attached instead of "the auth docs seem wrong".

reader → pre-addressed issue → triage → agent writes a PR → a person merges

• It answers either way. Actionable or not, the issue gets a reply and a label (ready or needs-info). An intake queue that answers nothing is worse than none.
• It cannot assert its way out. The agent follows the same SKILL.md you do. What it could not establish from the code goes in coverage.out_of_scope, not into a claim under somebody's name.
• It opens, it never merges. The change arrives as a pull request that has already run validate and docs --check. A human still reviews it.
• No API key? Triage still runs, still answers on the issue, still labels it. It just doesn't write anything.

Release notes that know what they touched — vibex changelog

Builds the release list from commit history — and with --specs, what each commit did to the documented system. It becomes a Changes panel in the dashboard, beside the diagrams those commits moved.

vibex changelog HEAD --specs docs/ -o changelog.json --md CHANGES.md
vibex dashboard docs/index.html docs --changelog changelog.json

If the history doesn't use conventional-commit prefixes, sections are inferred from the files each commit touched — and the output says so, in the document: "treat the grouping as a rough sort, not as the author's intent."

---

Nothing leaves the machine

An architecture diagram is a reconnaissance map of your system — table names, service topology, auth boundaries, every internal route. It's the exact thing you can't paste into someone else's SaaS. So vibeX doesn't have a server.

There is nothing to review, because there is nowhere for it to go.

What the generated file does not do — verified in the source

• No fetch, XMLHttpRequest or WebSocket, anywhere in the viewer runtime
• No CDN, no web fonts, no analytics, no telemetry — the system font stack and nothing else
• PNG export renders through an in-memory blob; it never touches the network
• Pull the cable out of the wall and it still pans, zooms, searches and exports

Put it on S3 behind SSO, internal nginx, a private Pages site, a Confluence attachment, committed next to the code, or file://. No account to view it. No seats. No expiry. Hand it to a contractor, an auditor, or the new hire on their first morning. It's a file.

Viewer shortcuts — search, deep links, source links, export

A PNG of a 40-table schema is a wall. This one you can interrogate:

/ search · t theme · 0 fit · +/- zoom · r reset layout · s save layout · Esc clear

Drag any box to move it and its lines re-route around the other boxes. To keep it, click Save layout. The page writes nothing itself; pick one:

1. Copy prompt: paste it to your coding agent. It carries the JSON and the steps.
2. Copy JSON: save it to a file and run vibex layout <spec.json> <file>.
3. Raise an issue: prefilled, when meta.repository.url is set. Intake applies it in a pull request.

The positions land in the spec's layout.positions; every render after that draws the boxes there.

Click any node for its columns, fields, params and relationships. #node=<id> deep-links to one specific table in one specific diagram — so you can send someone the thing, not "it's in the doc somewhere." SVG and PNG export produce standalone files in the current theme. Mermaid exports the diagram as .mmd, for Markdown that renders Mermaid (GitHub, GitLab, Notion). vibex render writes the .mmd beside every HTML it makes; vibex mermaid <spec> prints it.

Set meta.repository and sources: [{path, line}] and every node links back to the exact line on GitHub or GitLab.

Layout — what lives where, and how to add a diagram type

bin/vibex.mjs            CLI: validate, render, import, dashboard, docs, changelog, demo, types
schemas/                 JSON Schema per type (the authoring contract)
examples/                one example spec per type
renderers/<type>/        JSON -> SVG body
renderers/docs/          claim graph, anchors, markdown export
renderers/shared/        validate, layout (grid, orthogonal routing, edge lanes), svg styles, template, dashboard
importers/               openapi, graphql (own SDL parser), prisma
assets/template.html     single-diagram shell; slots are <!-- VIBEX:* --> comments
assets/dashboard.html    multi-diagram shell: sidebar, overview, cross-links
assets/viewer.js|css     shared viewer runtime, inlined into both shells
assets/icon.svg          the mark (monochrome, currentColor)
test/                    node:test suite + fixtures
SKILL.md                 agent instructions (Claude Code / Cursor skill)

A new diagram type is a schema, a validator function, a renderer that emits data-node-id / data-edge-from|to, and a line in renderers/shared/render.mjs.

Install

npx skills add Raja0sama/vibex -g -a claude-code -a codex -y   # Claude Code + Codex

/plugin marketplace add Raja0sama/vibex     # or, inside Claude Code
/plugin install vibex@vibex

The CLI comes with it and is what the skill drives. If you want it on your PATH as well, or pinned to a published release rather than a clone of main:

npm i -g @vibex/vibex               # adds the `vibex` command
npx @vibex/vibex demo out           # or run it once without installing anything

The unscoped vibex on npm is an unrelated package by another author. Always install @vibex/vibex.

Node 18+. Zero required dependencies. The optional yaml package is only needed if your OpenAPI document is YAML rather than JSON.

On the roadmap — built for one service, going to a system of them

• Request workflows — follow one request across service boundaries: the call in, the services it touches, the events it publishes, the tables it writes. C4 shows what could talk to what; this shows what actually happens when somebody presses buy.
• Monorepo support — one repository, many packages, one dashboard. Specs beside the package they describe, anchors that resolve inside it, and a root view that stitches them together without anyone maintaining a list by hand.
• One logical system — shipped in 0.7 as the System view (links, above). Next for it: which service owns which table.
• A GitHub Action that runs in your CI, regenerates on every pull request, and comments what moved — "2 tables, 3 endpoints." Still no server.
• A hosted tier, for teams who would rather buy the outcome than own the pipeline. The self-hosted path stays free and stays supported.

These are being designed, not finished. If one of them is the reason you'd adopt this, say so — that is the fastest way to influence it.

License

MIT, see LICENSE.

Prior art

Diagrams-as-code is a well-populated field, and vibeX stands on a lot of it: Mermaid and PlantUML for turning text into a picture, Structurizr for treating C4 as a model rather than a drawing, DBML for schema-to-ERD, Graphviz for deterministic layout, and tt-a1i/archify (MIT)

Never stale. Never leaves.
