1. WaddleCorp Pentest

This project was based in part on capsulecorp-pentest and a huge shout out to R3dy for the ground work!

The WaddleCorp Pentest is a virtual network managed by Vagrant and Ansible. It contains virtual machines configured with various vulnerable services. This project can be used to learn penetration testing in a standalone environment. The primary differences between CapsuleCorp and WaddleCorp (aside from the change in theme from DBZ to Penguins) is that WaddleCorp is configured with a Kali linux machine and will be updated periodically to reflect exploits as they are researched and discovered.

Why is this cool?

Setting up a virtual network to learn penetration testing can be tedious as well as time/resource consuming. Everything in the waddlecorp environment is pretty much done for you already. Once you get Vagrant, Ansible and VirtualBox installed on your machine you only need to run a couple of vagrant commands to have a fully functioning Active Directory domain that you can use for hacking/learning/pentesting etc.

1.1. Requirements

In order to use the WaddleCorp Pentest network you must have the following:

• VirtualBox

  • https://www.virtualbox.org/wiki/Downloads

• Vagrant

  • https://www.vagrantup.com/downloads.html

• Ansible

  • https://docs.ansible.com/ansible/latest/installation_guide/index.html

• Quad-core CPU with 16GB RAM is recommended.

  • With 8GB or less you could still use the project but only run 2 or 3 VMs at a time.
  • For All VMs running at once 16GB is required.

1.2. Current Functionality

• Active directory domain with one DC and 3 server members. All windows server have evaluation licenses, which are activated on installation (for 180 days)
  • Domain Controler: skipper.waddlecorp.local
  • Server 01: vegeta.waddlecorp.local
  • Server 02: kowalski.waddlecorp.local
  • Server 03: rico.waddlecorp.local
  • Wrkstn 01: tien.waddlecorp.local
  • Server 04: private.waddlecorp.loca
• Print Nightmare server on private
• Vulnerable Jenkins server on vegeta
• Vulnerable Apache Tomcat server on rico
• Vulnerable MSSQL server on kowalski
• Vulnerable MS17-010 on tien
• Kali Pentest Box
  • Impacket

1.3. OSX Configuration

In order to manage Windows hosts you'll have to install pywinrm with pip inside the ansible virtual environment

I prefer to run ansible in a virtualenv

cd <path you are working from>
virtualenv ansible
source ansible/bin/activate
pip install ansible
pip install pywinrm

If you receive the following error

objc[3534]: +[__NSCFConstantString initialize] may have been in progress in another thread when fork() was called.
objc[3534]: +[__NSCFConstantString initialize] may have been in progress in another thread when fork() was called. We cannot safely call it or ignore it in the fork() child process. Crashing instead. Set a breakpoint on objc_initializeAfterForkError to debug.

Apply the bandaid fix

export OBJC_DISABLE_INITIALIZE_FORK_SAFETY=YES

2. Installation

For a detailed installation walkthrough check out

• MacOS Setup Guide

• Windows Setup Guide

2.1. Configure the windows hosts

The first thing you should do is bring up and provision Skipper the domain controller. This system will likely take the longest to bring up because the dcpromo stuff just takes a while.

Note: if you are running vagrant with sudo. use sudo -E vagrant option to run vagrant

Bring up the VM

vagrant up skipper

Provision the VM

vagrant provision skipper

Repeat the above two commands for the other boxes or you can simply leave out machine specification to run all of them.

WARNING: running all machines is resource intensive please make sure you understand your machines specifications before doing this!

...WARNING...

This section of the provision is expected to take a while because after a dcpromo it takes a long time for the system to reboot.

TASK [promotedc : Set a static address to 172.28.128.100] **********************
changed: [skipper]

TASK [promotedc : Change hostname to skipper] *************************************
ok: [skipper]

TASK [promotedc : Install Active Directory Services] ***************************
ok: [skipper]

TASK [promotedc : Promote skipper to domain controller] ***************************
changed: [skipper]

TASK [promotedc : Reboot after promotion] **************************************

2.2. Configure your pentest platform

Bring up the virtual machines using Vagrant. First cd into the project directory, for example: cd ~/waddlecorp-pentest. Take note of the RDP port that gets forwarded to your localhost.

vagrant up pentest

Provision the pentest machine.

vagrant provision pentest

You can access your pentest machine either using your preferred RDP client to connect to the xrdp listener or via SSH with.

vagrant ssh pentest
