RecordPanel

A powerful React SDK for screen recording with camera and audio support

Features • Installation • Quick Start • API Reference • Examples

---

🎬 Demo

Click the image above to watch RecordPanel in action - screen recording with camera and audio support

---

Overview

RecordPanel is a feature-rich React SDK that enables screen recording with camera and audio capture capabilities. It provides a beautiful, draggable floating UI with real-time audio feedback, making it perfect for creating video tutorials, bug reports, or any application that requires screen recording functionality.

Features

✨ Core Features

• 🎥 Screen Recording - Capture your entire screen or specific windows
• 📹 Camera Support - Include your webcam feed with circular preview (Loom-style)
• 🎤 Audio Capture - Record microphone and system audio simultaneously
• 🎨 Beautiful UI - Modern, draggable floating panel with smooth animations
• 📊 Audio Feedback - Real-time visual audio level indicators
• ⏸️ Pause/Resume - Control recording playback on the fly
• 🔄 Restart - Quickly restart recordings without re-requesting permissions
• ⏱️ Duration Display - Real-time recording duration in MM:SS format
• 🎯 Simple API - One-line capture() method for quick integration

🎨 UI Features

• Draggable floating panel (drag anywhere except buttons)
• Circular camera preview (120px, Loom-style)
• Compact, modern design
• Real-time audio level visualization
• Recording indicator with pulsing red dot
• Configurable theme (light, dark, auto)
• Customizable stop button text

🔧 Technical Features

• TypeScript support with full type definitions
• Tree-shakeable (only imports what you use)
• Zero CSS conflicts (scoped styles)
• Browser permission management
• Automatic codec fallback (VP9 → VP8 → MP4)
• Memory-efficient blob handling
• Pause/resume duration tracking

Installation

npm install recordpanel

or

yarn add recordpanel

or

pnpm add recordpanel

Peer Dependencies

RecordPanel requires React 18+ or React 19+:

npm install react react-dom

Quick Start

1. Wrap Your App

Wrap your application with RecordPanelHost at the root level:

import { RecordPanelHost } from 'recordpanel'
import 'recordpanel/styles'

function App() {
  return (
    <RecordPanelHost>
      <YourApp />
    </RecordPanelHost>
  )
}

2. Use the Hook

Use the useRecordPanel hook in any component:

import { useRecordPanel } from 'recordpanel'

function MyComponent() {
  const recorder = useRecordPanel()

  const handleRecord = async () => {
    // Simple one-line API
    const result = await recorder.capture({
      cameraEnabled: true,
      audioEnabled: true
    })

    console.log('Recording:', result)
    // result contains: { blob, url, mimeType, size }
  }

  return <button onClick={handleRecord}>Start Recording</button>
}

3. Complete Example

import { useState } from 'react'
import { RecordPanelHost, useRecordPanel } from 'recordpanel'
import 'recordpanel/styles'

function RecordingComponent() {
  const [recording, setRecording] = useState(null)
  const recorder = useRecordPanel()

  const handleCapture = async () => {
    try {
      const result = await recorder.capture({
        cameraEnabled: true,
        audioEnabled: true
      })

      setRecording(result)

      // Download the recording
      const a = document.createElement('a')
      a.href = result.url
      a.download = `recording-${Date.now()}.webm`
      a.click()

      // Clean up
      URL.revokeObjectURL(result.url)
    } catch (error) {
      console.error('Recording failed:', error)
    }
  }

  return (
    <div>
      <button onClick={handleCapture}>Record Screen</button>
      {recording && (
        <video src={recording.url} controls />
      )}
    </div>
  )
}

function App() {
  return (
    <RecordPanelHost>
      <RecordingComponent />
    </RecordPanelHost>
  )
}

API Reference

RecordPanelHost

The root component that provides the recording context to your app.

Props

interface RecordPanelHostProps {
  children: ReactNode
  config?: RecorderConfig
}

Configuration

interface RecorderConfig {
  theme?: 'light' | 'dark' | 'auto'  // Default: 'auto'
  stopButtonText?: string             // Default: 'Send'
}

Example:

<RecordPanelHost
  config={{
    theme: 'dark',
    stopButtonText: 'Finish'
  }}
>
  <YourApp />
</RecordPanelHost>

useRecordPanel()

Returns the recorder API object. Must be used within a component wrapped by RecordPanelHost.

const recorder = useRecordPanel()

API Methods

recorder.capture(options?)

The simplest way to record. Starts recording, shows UI, waits for user to stop, and returns the result.

const result = await recorder.capture({
  cameraEnabled?: boolean  // Default: true
  audioEnabled?: boolean    // Default: true
})

// Returns: RecordingResult

Example:

const handleCapture = async () => {
  try {
    const result = await recorder.capture({
      cameraEnabled: true,
      audioEnabled: true
    })
    console.log('Recording complete:', result)
  } catch (error) {
    console.error('Capture failed:', error)
  }
}

recorder.start(options?)

Starts recording. Requests permissions if not already granted.

await recorder.start({
  cameraEnabled?: boolean  // Default: true
  audioEnabled?: boolean    // Default: true
})

recorder.stop()

Stops recording and returns the result.

const result = await recorder.stop()
// Returns: RecordingResult | null

recorder.pause()

Pauses the current recording.

recorder.pause()

recorder.resume()

Resumes a paused recording.

recorder.resume()

recorder.restart()

Stops the current recording and starts a new one. Preserves permissions if already granted.

await recorder.restart()

recorder.show()

Shows the recorder UI overlay.

recorder.show()

recorder.hide()

Hides the recorder UI overlay.

recorder.hide()

recorder.setConfig(config)

Updates the recorder configuration dynamically.

recorder.setConfig({
  theme: 'dark',
  stopButtonText: 'Finish'
})

State Methods

recorder.getState()

Returns the current recording state.

const state = recorder.getState()
// Returns: 'idle' | 'requesting' | 'recording' | 'paused' | 'stopped'

recorder.isRecording()

Checks if currently recording.

const isRecording = recorder.isRecording() // boolean

recorder.isPaused()

Checks if recording is paused.

const isPaused = recorder.isPaused() // boolean

recorder.isVisible()

Checks if the UI overlay is visible.

const isVisible = recorder.isVisible() // boolean

recorder.getRecordingDuration()

Gets the current recording duration in seconds (includes pause time handling).

const duration = recorder.getRecordingDuration() // number (seconds)

Types

RecordingResult

interface RecordingResult {
  blob: Blob           // The recording blob
  url: string          // Object URL (revoke after use)
  mimeType: string     // e.g., 'video/webm' or 'video/mp4'
  size: number         // Size in bytes
}

RecorderState

type RecorderState = 'idle' | 'requesting' | 'recording' | 'paused' | 'stopped'

RecorderConfig

interface RecorderConfig {
  theme?: 'light' | 'dark' | 'auto'
  stopButtonText?: string
}

Examples

Simple Capture

function SimpleRecording() {
  const recorder = useRecordPanel()

  const handleRecord = async () => {
    const result = await recorder.capture()
    console.log('Recording:', result)
  }

  return <button onClick={handleRecord}>Record</button>
}

Advanced Control

function AdvancedRecording() {
  const recorder = useRecordPanel()
  const [isRecording, setIsRecording] = useState(false)

  const handleStart = async () => {
    await recorder.start({
      cameraEnabled: true,
      audioEnabled: true
    })
    setIsRecording(true)
  }

  const handleStop = async () => {
    const result = await recorder.stop()
    if (result) {
      console.log('Recording:', result)
      setIsRecording(false)
    }
  }

  const handlePause = () => {
    recorder.pause()
  }

  const handleResume = () => {
    recorder.resume()
  }

  return (
    <div>
      {!isRecording ? (
        <button onClick={handleStart}>Start Recording</button>
      ) : (
        <>
          <button onClick={handlePause}>Pause</button>
          <button onClick={handleResume}>Resume</button>
          <button onClick={handleStop}>Stop</button>
        </>
      )}
    </div>
  )
}

With State Management

function RecordingWithState() {
  const recorder = useRecordPanel()
  const [recording, setRecording] = useState(null)
  const [duration, setDuration] = useState(0)

  useEffect(() => {
    if (recorder.isRecording()) {
      const interval = setInterval(() => {
        setDuration(recorder.getRecordingDuration())
      }, 1000)
      return () => clearInterval(interval)
    }
  }, [recorder.isRecording()])

  const handleCapture = async () => {
    const result = await recorder.capture()
    setRecording(result)
  }

  return (
    <div>
      <button onClick={handleCapture}>Record</button>
      {recorder.isRecording() && (
        <div>Recording: {Math.floor(duration / 60)}:{(duration % 60).toFixed(0).padStart(2, '0')}</div>
      )}
      {recording && (
        <video src={recording.url} controls />
      )}
    </div>
  )
}

Custom Theme

function ThemedApp() {
  return (
    <RecordPanelHost
      config={{
        theme: 'dark',
        stopButtonText: 'Finish Recording'
      }}
    >
      <YourApp />
    </RecordPanelHost>
  )
}

UI Features

The RecordPanel UI provides a comprehensive set of controls:

Floating Panel

• Draggable - Click and drag anywhere on the panel (except buttons) to reposition
• Compact Design - Small footprint, doesn't obstruct your screen
• Smooth Animations - Slide-in animation when appearing

Camera Preview

• Circular Design - 120px circular preview (Loom-style)
• Positioned Above Controls - Appears above the control bar when enabled
• Recording Indicator - Red pulsing dot in the top-right corner
• Audio Feedback - Visual audio level bar at the bottom

Control Bar

• Duration Display - Shows recording time in MM:SS format
• Audio Meter - Real-time audio level visualization (5 bars)
• Camera Toggle - Enable/disable camera feed
• Audio Toggle - Enable/disable microphone
• Pause/Resume - Control recording playback
• Restart - Restart recording (preserves permissions)
• Stop/Send - Stop recording and get result (configurable text)
• Close - Hide the UI overlay

Styling & Customization

CSS Variables

RecordPanel uses CSS variables that you can customize:

:root {
  --recordpanel-primary: 221 83 53;
  --recordpanel-primary-foreground: 0 0 100;
  --recordpanel-border: 214 218 222;
  --recordpanel-muted: 248 249 250;
  /* ... more variables */
}

Theme Configuration

<RecordPanelHost
  config={{
    theme: 'auto', // 'light' | 'dark' | 'auto'
    stopButtonText: 'Send'
  }}
>
  <YourApp />
</RecordPanelHost>

The auto theme automatically follows the system preference.

Custom Styles

All RecordPanel styles are scoped with the .recordpanel-* prefix to avoid conflicts. You can override styles if needed:

.recordpanel-overlay {
  /* Your custom styles */
}

Browser Support

RecordPanel works in all modern browsers that support:

• MediaRecorder API - Chrome 47+, Firefox 25+, Safari 14.1+, Edge 79+
• getDisplayMedia - Chrome 72+, Firefox 66+, Safari 13+, Edge 79+
• getUserMedia - Chrome 53+, Firefox 36+, Safari 11+, Edge 12+

System Audio Capture

System audio capture is supported in:

• ✅ Chrome/Edge (Windows, macOS, Linux)
• ❌ Firefox (not supported)
• ❌ Safari (not supported)

Recommended Browsers

For the best experience, use:

• Chrome/Edge (full feature support)
• Firefox (screen + microphone only)
• Safari (screen + microphone only)

TypeScript Support

RecordPanel is written in TypeScript and provides full type definitions:

import {
  RecordPanelHost,
  useRecordPanel,
  type RecordingResult,
  type RecorderConfig,
  type RecorderState
} from 'recordpanel'

Troubleshooting

Permissions Not Requested

If permissions aren't being requested, ensure:

• You're using HTTPS (or localhost)
• The browser supports the required APIs
• No browser extensions are blocking permissions

Recording Stops Early

If recordings are shorter than expected:

• Check browser console for errors
• Ensure sufficient disk space
• Check if browser is closing the MediaRecorder

Audio Not Recording

• Verify microphone permissions are granted
• Check browser audio settings
• System audio requires Chrome/Edge on desktop

UI Not Appearing

• Ensure RecordPanelHost wraps your app
• Check that recorder.show() is called
• Verify CSS is imported: import 'recordpanel/styles'

Memory Issues

Always revoke object URLs after use:

const result = await recorder.capture()
// Use result.url
URL.revokeObjectURL(result.url) // Important!

Development

Building the Library

npm run build:lib

This creates a library build in the dist folder.

Running the Demo

npm run dev

Project Structure

src/
  recordpanel/
    ├── index.ts              # Main exports
    ├── RecorderHost.tsx      # Host component
    ├── RecorderContext.tsx   # Context & hook
    ├── RecorderUI.tsx        # UI component
    ├── recorder.ts            # Core recording logic
    └── styles.css            # Scoped styles

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

1. Fork the repository
2. Create your feature branch (git checkout -b feature/amazing-feature)
3. Commit your changes (git commit -m 'Add some amazing feature')
4. Push to the branch (git push origin feature/amazing-feature)
5. Open a Pull Request

License

MIT License - see LICENSE file for details.

Acknowledgments

• Built with React
• Icons from Lucide React
• UI components inspired by shadcn/ui

---

Made with ❤️ by GeekyAnts

GitHub • Issues • Pull Requests
