Contributing to TMS

Getting Started

Prerequisites:

• Rust
• Flutter
• Protobuf
• Pre-Commit (optional but recommended)

The dart protobuf plugin requires "$HOME/.pub-cache/bin" to be added to your PATH

Installation:

1. Clone and install the pre-commit hooks:

   git clone https://github.com/<USERNAME>/TMS.git
   cd TMS
   pre-commit install

2. Build the server:

   cargo build

3. Install client dependencies:

   dart pub global activate protoc_plugin
   cd client
   flutter pub get

Compiling

1. Compile the server (from workspace)

• If protobuf is installed the buildscript should automatically compile the protobuf files into generated outputs prior to compiling the server.

  cargo build

2. Compile the client

• The Flutter client uses protobuf, riverpod and freezed which generates code for state management and data models.
• It's recommended to run the build_runner to generate any lingering code. Or run it with watch to automatically regenerate code.
• And then compile the protobuf (flutter sadly doesn't have a build_runner binding for protobuf)

  protoc --proto_path=protos --dart_out=grpc:client/lib/generated protos/**/*.proto
  cd client
  dart run build_runner build --delete-conflicting-outputs
  flutter build

Project Structure

Directory	Description
/database	key-value database library using sled
/launcher	Launcher and entry code for the server application
/protos	Protocol Buffers definitions for communication between client and server
/server	Server-side code
/client	Client-side code (in flutter)
/docs	Documentation for the project

Development Workflow

Branch Naming Convention:

• feat/<feature-name>
• fix/<issue-number>

Committing:

• TMS uses pre-commit hooks for linting and catching common issues before committing
• Use conventional and meaningful commit messages: feat:, fix:, docs:, refactor:
• Keep commit messages concise and descriptive under 50 characters
• Example: fix: Updated export column order to match OJS

Pull Requests:

1. Create feature branch from master
2. Make changes, test locally
3. Update documentation relating to feature if possible
4. Push and open PR to master
5. Ensure CI-CD is compliant with changes
6. Prefer squash merge

Code Style

Rust:

• Use Rustfmt for code formatting
• Use 2 spaces for indentation
• Use 120 line width
• Use snake_case for variable and function names
• Use PascalCase for struct, trait and enum names
• Use consistent naming conventions

Flutter:

• Use 2 spaces for indentation
• Use 120 line width
• Use camelCase for variable and function names
• Use PascalCase for class, enum and interface names
• Use consistent naming conventions

Programming Guidelines Flutter

• Order of Widget priority
  • StatelessWidget for static content
  • ConsumerWidget for rebuilding content (dependent on providers)
  • HooksConsumerWidget for rebuilding content with inline logic

UI Guidelines

Font

Font Type	Font Name	Font Size
Heading	Ubuntu Mono	16px
Body	Ubuntu Mono	14px
Supporting	Ubuntu Mono	12px

(Yes it's monoblock, I don't want to hear it)

Color Palette

Color Type	Color Name	Hex Code
Primary	Mint Green	#009485
Secondary	Persian Blue	#009485
Supporting Error	Red	#D92B2B
Supporting Warning	Orange	#D9822B
Supporting Success	Green	#2BD92B
Supporting Info	Blue	#2B65D9
Neutral	Shadow Gray	#20222F
