b-code specification

Current Version

Current version of the document is 0.0.1-draft.

Welcome

Hello, visitor! If you've come across this document, it likely holds your interest. We encourage you to read on.

Introduction

Purpose of b-code

This document presents a proposal for a specification of a text-based protocol called b-code, designed to control small robots such as Otto, Zumo, or mBot. b-code aims to serve DIY and toy robots in a similar manner to how G-code functions for 3D printers and CNC machines.

One of the objectives of b-code is to permit the development of reusable remote control apps compatible with different robot models.

Even though b-code is intended to cover a wide range of tiny robots capabilities, it is extensible to accommodate specific features of certain robots.

Cheat Sheet

For a quick overview of the b-code commands, responses, and examples, see the CHEATSHEET.md document. It provides a concise summary of the protocol's key elements for easy access during development.

Related projects

b-code descriptor

The b-code protocol is minimalistic, to be implemented on robots with limited sowftare resources like Arduino controllers.

For example, the command A 10 could make a robot sing happy birthday while weaving its arms. It actually depends on the robot implementation.

That's why this protocol is completed by the specification of a descriptor file (in YAML format) which describes the capabilities of a specific robot model (catalogs of actions, units of movement, list of sensors, units, id card of the robot, etc.).

The descriptor file specification has its own Github repository: https://github.com/verdi8/b-code-desc

b-code web remote control app

Specification

Generalities

b-code is the normalized name of the protocol. It is lowercase with a hyphen.

The protocol is designed for communication between a controller (e.g., a computer, smartphone, or tablet) and a robot (the device being controlled).

Robot concepts implied by the specification

The b-code specification is designed around several fundamental concepts and terms. These terms are defined below for a better understanding of the specification.

Robot

A robot is a physical device capable of moving and performing actions. It typically includes components such as motors, sensors, and actuators that enable it to interact with its environment.

Movements

A movement is a change in the robot's location or orientation, executed by the robot's locomotion system. Movements are quantified by a unit of movement and are categorized as:

• Translation: A movement that changes the robot's location without altering its orientation (e.g. moving forward, backward, left, or right).
• Rotation: A movement that changes the robot's orientation without altering its location (e.g. turning left or right).

A movement is also defined by a value called a unit of movement.

There are two types of units of movement: one for translation and another for rotation.

The unit of movement can represent various types of measurements, such as:

• a standardized unit, such as centimeters, millimeters or inches for a distance, degrees or radians for an angle
• a number of wheel turns for a wheeled robot, both sides for translation, one side for rotation
• the number of steps for a walking robot

The unit of movement is a value that depends on the robot's hardware and software design.

Actions

Actions are high-level operations that allow robots to interact with their environment or express themselves through a combination of gestures, sounds, and displays.

A gesture is a sequence of movements of parts of the robot that - in opposition to a movement - does not change the robot's location or orientation. Examples include waving an arm, nodding a head, or blinking an eye.

Sounds are audio signals produced by the robot. Examples include beeps, melodies, or voice messages. Sounds are human-hearable.

Displays are visual outputs produced by the robot. Examples include LED matrixes, screen messages, or animations.

Gestures, sounds, and displays are considered primary actions, meaning they represent the basic building blocks of robot operations. However, the term action in the rest of this specification refers to either:

• a combination of these primary actions (e.g., a robot waving its arm while playing a melody and showing an animation), or
• a high-level operation that cannot be described as merely a gesture, sound, or display (e.g., a robot performing a complex task like "nod" or "greet").

Actions are used for purposes like expressing emotions, providing feedback, or interacting with the robot's environment.

State and sensors

A robot may have various sensors to perceive its environment and gather data. These sensors can include, but are not limited to: proximity sensors (e.g., ultrasonic, infrared), light sensors, temperature sensors, accelerometers and gyroscopes.

A robot may also maintain an internal state, which represents its current condition or status. The state can include information such as: battery level, operational mode (e.g., idle, active, error), position and orientation.

Sensors are more about external data gathering, while the state is about the internal status of the robot.

Sensor readings and state information can be accessed and queried through specific commands defined in this specification.

General protocol rules

b-code operates as a request-response protocol. The controller sends a command to the robot, which processes the command and returns a response.

The robot does not send any messages without a prior request from the controller.

The controller must wait for the robot's complete multiline response before issuing another command.

Although the specification primarily utilizes ASCII, UTF-8 (without BOM) is the default encoding for future extensions.

Syntax

Commands

The general format of a command consists of a single line of text structured as follows:

<command code> <arg1> <arg2> ... <argN>

The command :

• begins with a command code, which is a sequence of ASCII uppercase letters and digits (no spaces, no special characters, a type named [CODE] later in this document),
• no spaces are allowed before the command code,
• is followed by a list of arguments, separated by one or more spaces. Arguments may vary in type depending on the command.
• ends with a single newline character (\n or 0x0A).
• when more arguments are provided than required for a specific command, the extra arguments are ignored.

The maximum length of a command line is 64 characters, including the newline character.

Note: The types mentioned in the syntax (e.g., [INTEGER], [FLOAT], or [CODE]) are described in detail in the Types section at the end of this document.

Responses

Response structure

There can be multiple responses to a command, depending on the command. Each response is a single line of text, with the following structure:

<response type code> <complement1> <complement2> ... <complementN>

A response line:

• starts with a response code, which is of type [CODE] (a sequence of ASCII letters and digits, no spaces, no special characters),
• is followed by a list of complements, separated by a single or multiple spaces. Complements can be of different types (depending on the response).
• is ended by a single newline character (\n or 0x0A).

Terminating response line

A sequence of response lines is ended by a terminating response, with a response type code OK or ERR. A terminating response means that no more responses will be sent by the robot for the current command, and the controller can send another command.

The OK response type has no complement.

The ERR response has the following structure:

ERR <error code>

where <error code> is an integer (type [INTEGER]) that identifies the specific error.

Sequence diagram

Examples

In the follwing document, commands are represented by a line starting with >> and responses by lines starting with <<.

Example 1: Successful command execution

>> T F 10
<< OK

Example 2: Command execution with an error

>> T X 10
<< ERR 2

Example 3: Command with multiple responses

>> S TEMP
<< TEMP 25.3
<< OK

Movements

As explained above, a movement is a change in the robot's location or orientation.

Direction

The following section describes commands related to movements of the robot in a given direction.

These directions imply the robot to have a front, a back, a left and/or a right side. Even though not all robots may have these sides physically defined, they should be logically defined for the purpose of movement commands.

Unit of Movement

In the following commands, some command arguments are described as a <unit of movement>.

For a translation, the unit of movement is a [FLOAT] value representing the distance the robot should move. But for a rotation, the unit of movement is representing the angle the robot should rotate.

Note

As the unit of movement is a [FLOAT] value, it can be a partial value, such as 0.5 or 1.7. It is up to the robot to determine how to handle partial values. It must round them to the upper value it can handle. For example:

• for a robot with standardized units: > - a value of 0.7 could be rounded to 1 cm wth a 1 cm precision for a distance
  • a value of 1.7 could be rounded to 2 degrees with a 1 degree precision for an angle
• for a wheeled robot with a 5 degrees precision, a value of 1.2 could be rounded to a 435 degree wheel rotation (1.2 * 360 / 5)
• for a walking robot, a value of O.1 could be rounded to 1 step

Also, the unit of movement can be negative, positive or zero:

• a positive value indicates movement in the requested direction.
• a negative value indicates movement in the opposite direction.
• a zero value indicates no movement.

Translation

A translation is a movement that changes the robot's location without altering its orientation.

The distance of a translation is specified using a unit of movement.

Command:

T <direction> <unit of movement>

with <direction> (type [CODE]) is the direction of the movement. It can be one of the following letters:

• F: Forward
• B: Backward
• L: Left
• R: Right
• U: Up
• D: Down

It can also be a combination of these letters, such as FL for Forward-Left or BR for Backward-Right.

These codes are predefined values for these specific directions. Other values are allowed, but it is up to the robot implementation to interpret them.

Note

If the robot cannot move in one of these directions, it should ignore the command.

<unit of movement> (type [FLOAT]), see the Unit of Movement section above.

Response:

The only response to this command is a terminating OK or ERR <error code>.

Examples:

Move forward by 10 units of movement:

>> T F 10
<< OK

Move backward on the left by 3.5 units of movement:

>> T BL 5.5
<< OK

Rotation

A rotation is a movement that changes the robot's orientation without altering its location.

The angle of a rotation is specified using a unit of movement.

Command:

R <direction> <unit of movement> with <direction> (type [CODE]) is the direction of the movement. It can be one of the following letters:

• L: Left
• R: Right
• U: Up
• D: Down

It can also be a combination of these letters, such as UL for Up-Left or DR for Down-Right.

These codes are predefined values for these specific directions. Other values are allowed, but it is up to the robot implementation to interpret them.

Note

If the robot cannot rotate in one of these directions, it should ignore the command.

<unit of movement> (type [FLOAT]), see the Unit of Movement section above.

Response:

The only response to this command is a terminating OK or ERR <error code>.

Examples:

Rotate left by 90 units of movement:

>> R L 90
<< OK

Rotate up-right by 45.5 units of movement:

>> R UR 45.5
<< OK

Gestures, sounds, displays and actions

Gestures, sounds, displays and action are concepts described above in the Robot concepts implied by the specification section.

Gestures

Command:

G <gesture code> with <gesture code> (type [INTEGER]) is an integer that identifies the specific gesture to be performed by the robot.

It is up to the robot implementation to define the mapping between gesture codes and actual gestures.

Note

The gesture code 0 is usually reserved for stopping any ongoing gesture and returning the robot to a neutral position.

Response:

A terminating OK or ERR <error code>.

Sounds

Command:

S <sound code> [<sound volume>] with <sound code> (type [INTEGER]) is an integer that identifies the specific sound to be played by the robot.

Note

The sound code 0 is usually reserved for stopping any ongoing sound.

<sound volume> (type [FLOAT], optional) is a floating-point value representing the volume at which the sound should be played. It typically ranges from 0.0 (mute) to 1.0 (maximum volume). If not provided, the default volume level is used. If provided but not supported by the robot, it should be ignored. Out of range values should be clamped to the nearest valid value (e.g., a value of 1.5 should be treated as 1.0).

Response:

A terminating OK or ERR <error code>.

Displays

Command:

D <display code> [<display number>] with <display code> (type [INTEGER]) is an integer that identifies the specific display to be shown by the robot.

Note

The display code 0 is usually reserved for turning off the display.

<display number> (type [INTEGER], optional) is an integer that can be used to identify a specific instance of the display, if the robot supports multiple displays. If not provided, the default display instance is used (conventionally 0).

Response:

A terminating OK or ERR <error code>.

Actions

Command:

A <action code> with <action code> (type [INTEGER]) is an integer that identifies the specific composite action to be performed by the robot.

Specific action:

A 0 is a reserved action code that makes the robot stop all its ongoing actions immediately and return to a neutral state. It is an equivalent a 0 command for gestures, sounds, and displays.

Response:

A terminating OK or ERR <error code>.

State and sensor readings

Sensor reading

Command:

Q <sensor code> with <sensor code> (type [CODE]) is a string that identifies the specific sensor whose reading is being requested. The list of supported sensor codes depends on the robot implementation.

Response:

The response to this command consists of:

R <SENSOR_CODE> <value0> <value1> ... <valueN>

where <SENSOR_CODE> is the same as the requested <sensor code>, and <value0>, <value1>, ..., <valueN> are the readings from the specified sensor. The number and type of values depend on the specific sensor being queried.

This response is followed by a terminating OK or ERR <error code>.

State information

Command:

I <state code> with <state code> (type [CODE]) is a string that identifies the specific state information being requested. The list of supported state codes depends on the robot implementation.

Response:

The response to this command consists of:

R <STATE_CODE> <value0> <value1> ... <valueN>

where <STATE_CODE> is the same as the requested <state code>, and <value0>, <value1>, ..., <valueN> are the values representing the requested state information. The number and type of values depend on the specific state being queried.

Special commands

Stop

The stop command is used to immediately halt all ongoing actions and movements of the robot.

It is a safety feature that allows the controller to quickly stop the robot in case of an emergency or unexpected behavior.

Command:

0

Response:

A terminating OK.

NOP

The NOP (No Operation) command is used to check or maintain the communication between the controller and the robot without performing any action.

Command:

Z

Response:

A terminating OK.

Appendices

Errors

Error ranges

Error codes are strictly positive integers (greater than or equal to 1). Error codes are organized into ranges based on their categories:

Error code range	Description
0	Forbidden value. Error codes must be strictly positive integers.
1 to 99	Parsing errors. These errors imply that the command could not be understood and could not be submitted to the robot's logic.
100 to 199	Action errors. These errors relate to issues encountered while executing actions.

Generic errors

Error code	Message	Description
1	Parsing error	The command could not simply be understood.
2	Invalid command code	The command code is not a supported value.

Types

Types specification

Type	Description	Examples
[CHARACTER]	The [CHARACTER] type represents a single ASCII character. It is used to denote individual characters in commands or responses.	A, Z, 0, 9, !
[CODE]	The [CODE] type represents a string of ASCII letters and digits (no spaces, no special characters). A code has a maximum length of 16 characters.	ERROR, SENSOR1
[INTEGER]	A signed integer type that can represent whole numbers, both positive and negative. An integer is a 16-bit value, ranging from -32,768 to 32,767. Error codes are a specific use case of [INTEGER].	0, 42, -7
[FLOAT]	The [FLOAT] type corresponds to the float type in the C language, specifically a single-precision 32-bit IEEE 754 floating-point number. It can represent a wide range of values with a precision of approximately 6 to 7 decimal digits. Note that scientific notation is not supported.	5, 3.14, -10.00

Versioning

Versioning scheme

The versioning of the b-code specification follows the Semantic Versioning principles (SemVer 2.0.0).

Branching model

The b-code specification repository follows the following branching model:

• The main branch contains the latest stable release of the specification.
• The draft branch is used for ongoing development and integration of evolutions to the specification.

Contribution

Contributions to the b-code specification are welcome! If you have proposals for improvements, feel free to submit an issue on the GitHub repository.
