React InstantSearch widget that filters the dataset based on size facet values.
Equivalent of the offcial RefinementList widget but displaying size boxes as a grid instead of facet values checkboxes as a list.

---

Summary

• Demo
• Installation
• Usage
• Styling
  • CSS variables
• Requirements
• Options
• Example
• Browser Support
• Troubleshooting
• Contributing & Licence

Get started

Demo

Demo on CodeSandbox.

Installation

npm install @algolia/react-instantsearch-widget-size-refinement-list
# or
yarn add @algolia/react-instantsearch-widget-size-refinement-list

Usage

import React from 'react';
import ReactDOM from 'react-dom';
import { InstantSearch, SearchBox, Hits, Panel } from 'react-instantsearch-dom';
import algoliasearch from 'algoliasearch/lite';
import { SizeRefinementList } from '@algolia/react-instantsearch-widget-size-refinement-list';

// Import default styles
import '@algolia/react-instantsearch-widget-size-refinement-list/dist/style.css';

const searchClient = algoliasearch('appId', 'apiKey');

ReactDOM.render(
  <InstantSearch indexName="indexName" searchClient={searchClient}>
    <SizeRefinementList attribute="size" />
  </InstantSearch>,
  document.getElementById('root')
);

Styling

The widget ships with default styles that you can import either from the NPM package or directly from a CDN like JSDelivr.

import '@algolia/react-instantsearch-widget-size-refinement-list/dist/style.css';

<link
  rel="stylesheet"
  href="https://cdn.jsdelivr.net/npm/@algolia/react-instantsearch-widget-size-refinement-list/dist/style.css"
/>

CSS variables

The widget styles uses CSS variables that you can customize in your own CSS.
You can override CSS variables using the .ais-SizeRefinementList class.

Name	Type	Description
--transition-duration	time	Transition duration (used for hover, active, refined states).
--items-column-width	length	Items grid column width.
--items-gap	length	Items grid gap.
--refined-color-rgb	integer, integer, integer	The RGB values when an item is refined.
--refined-color-alpha	number	The alpha value when an item is refined.
--not-refined-rgb	integer, integer, integer	The RGB values when an item is not refined.
--not-refined-alpha	number	The alpha value when an item is not refined.
--border-alpha	number	The alpha value for the item border color when an item is not refined.

Options

Same options as the official RefinementList widget.

Option	Type	Required	Default	Description
attribute	string	true	-	The name of the attribute in the record.
defaultRefinement	string[]	false	[]	The value of the item selected by default.
operator	string ("or"|"and")	false	or	How to apply the refinements.
limit	number	false	10	How many facet values to retrieve.
showMore	boolean	false	false	Whether to display a button that expands the number of items.
showMoreLimit	number	false	20	Maximum number of displayed items. Only used when showMore is set to true.
searchable	boolean	false	false	Whether to add a search input to let the user search for more facet values.
transformItems	function	false	undefined	Modifies the items being displayed, for example, to filter or sort them. It takes items as argument and expects them back in return.
translations	object	false	-	A mapping of keys to translation values.

attribute

string | required

The name of the attribute in the record.

<SizeRefinementList attribute="size" />

defaultRefinement

string[]

The value of the item selected by default.

<SizeRefinementList defaultRefinement={['M']} />

operator

string ("or"|"and")

How to apply the refinements.

<SizeRefinementList operator="and" />

limit

number

How many facet values to retrieve.

<SizeRefinementList limit={10} />

showMore

boolean

Whether to display a button that expands the number of items.

<SizeRefinementList showMore={true} />

showMoreLimit

number

Maximum number of displayed items. Only used when showMore is set to true.

<SizeRefinementList showMoreLimit={20} />

searchable

boolean

Whether to add a search input to let the user search for more facet values.

<SizeRefinementList searchable={true} />

transformItems

function

Modifies the items being displayed, for example, to filter or sort them. It takes items as argument and expects them back in return.

<SizeRefinementList
  transformItems={(items) =>
    items.map((item) => ({
      ...item,
      label: item.label.toUpperCase(),
    }))
  }
/>

translations

object

A mapping of keys to translation values.

• showMore: the label of the “Show more” button. Accepts one boolean parameter that is true if the values are expanded, false otherwise.
• noResults: the label of the no results text when no search for facet values results are found.
• submitTitle: the alternative text of the submit icon.
• resetTitle: the alternative text of the reset button icon.
• placeholder: the label of the input placeholder.

<LoadMoreWithProgressBar
  translations={{
    showMore(expanded: boolean) {
      return expanded ? 'Show less' : 'Show more';
    },
    noResults: 'No results',
    submitTitle: 'Submit your search query.',
    resetTitle: 'Clear your search query.',
    placeholder: 'Search here...',
  }}
/>

Example

Clone this repository and go to the repo folder:

git clone git@github.com:algolia/react-instantsearch-widget-size-refinement-list.git && \
cd react-instantsearch-widget-size-refinement-list

Install the dependencies and start the example:

npm install && npm start
# or
yarn install && yarn start

Then open http://localhost:3000/ to see the example in action.

Browser support

Same as React InstantSearch it supports the last two versions of major browsers (Chrome, Edge, Firefox, Safari).

Please refer to the browser support section in the documentation to use React InstantSearch and this widget on other browsers.

Troubleshooting

Encountering an issue? Before reaching out to support, we recommend heading to our FAQ where you will find answers for the most common issues and gotchas with the library.

Contributing & Licence

How to contribute

We welcome all contributors, from casual to regular 💙

• Bug report. Is something not working as expected? Send a bug report.
• Feature request. Would you like to add something to the library? Send a feature request.
• Documentation. Did you find a typo in the doc? Open an issue and we'll take care of it.
• Development. If you don't know where to start, you can check the open issues that are tagged easy, the bugs or chores.

To start contributing to code, you need to:

1. Fork the project
2. Clone the repository
3. Install the dependencies: yarn
4. Run the development mode: yarn start
5. Open the project

Please read our contribution process to learn more.

Licence

Licensed under the MIT license.

---

About React InstantSearch

React InstantSearch is a React library that lets you create an instant-search result experience using Algolia’s search API. It is part of the InstantSearch family:

React InstantSearch | InstantSearch.js | Angular InstantSearch | Vue InstantSearch | InstantSearch Android | InstantSearch iOS

This project was generated with create-instantsearch-app by Algolia.
