Dynamic Query & RDash Builder

A small web application that lets users build SQL queries visually and generate Reveal dashboard (RDash) files backed by a lightweight ASP.NET server. The project includes a responsive client UI (vanilla HTML/CSS/JS) and a server that exposes REST endpoints to enumerate allowed tables, generate and persist queries, and serve Reveal dashboards.

Watch the project overview video: YouTube - Dynamic Query & RDash Builder

Repository layout

• client/ — static frontend assets (HTML, CSS, JS). Key files:

  • index.html — single-page UI for query creation, query list, and dashboard viewer.
  • scripts/main.js — client logic for interacting with the server API and Reveal SDK.
  • styles/main.css — styling for the UI.
  • create-dashboard.html, create-data-grid.html — helper pages used inside the dashboard iframe viewer.

• server/aspnet/ — ASP.NET Core server that wires up the Reveal SDK and provides API endpoints.

  • Program.cs — app startup, services and endpoints registration.
  • Reveal/ — Reveal-specific providers (e.g. DashboardProvider.cs).
  • Services/ — core services such as QueryService.cs, DatabaseService.cs, DashboardService.cs.
  • Queries/, Dashboards/ — runtime folders where generated query JSON files and RDash dashboards are saved.

What it does

• Let users visually select tables and fields to create SQL SELECT queries.
• Save query metadata and SQL on the server as JSON files (under server/aspnet/Queries).
• Generate and persist Reveal dashboard (.rdash) files (under server/aspnet/Dashboards).
• List existing queries and open them in a Reveal dashboard viewer (client uses Reveal SDK).

Tech stack

• Frontend: HTML, CSS, vanilla JavaScript, Reveal SDK (in-browser), jQuery (for Reveal SDK integration).
• Backend: .NET 8 (ASP.NET Core), Reveal SDK server-side integration.
• Data sources: PostgreSQL support is registered in Program.cs via builder.DataSources.RegisterPostgreSQL(); DatabaseService abstracts DB metadata reads.

Quick start (development)

Prerequisites:

• .NET 8 SDK installed
• PostgreSQL (if you plan to connect to a real database) or configure a data source compatible with Reveal SDK settings in appsettings.json.

Run the server:

1. Open a terminal and change to the server folder:

   cd server/aspnet

2. Restore and run the app (macOS / zsh):

dotnet restore
dotnet run

By default the client expects the API to be at http://localhost:5111 (see client/scripts/main.js constants API_BASE_URL and API_BASE). If your server runs on a different port, update those constants or set up a reverse proxy.

Serve the client:

The client folder contains static files. You can open client/index.html directly in the browser for local testing, or serve it from the ASP.NET app (e.g., configure static file middleware) or an HTTP static server such as live-server or http-server.

Important server endpoints (used by the client)

• GET /api/allowed-tables

  • Returns the list of allowed tables and metadata (display names, descriptions). The client uses this to populate the tables list in the query builder.

• GET /api/table-schema/{tableName}

  • Returns column schema for the named table. The client requests this when a table is selected to display available fields.

• POST /api/generate-query

  • Payload: { id, friendlyName, description, tableName, fields }
  • Generates a SQL SELECT for the requested fields, fetches column metadata, and writes a JSON query metadata file under Queries/.

• GET /api/queries

  • Lists available queries (reads files under Queries/ and returns metadata used to populate the grid view).

• DELETE /api/queries/{id}

  • Deletes the query JSON file and associated user_{id}.rdash dashboard if present.

• POST /api/generate-grid-dashboard/{queryId}

  • Generates a simple grid dashboard RDash for the query and saves it under Dashboards/user_{queryId}.rdash.

• GET /dashboards/names

  • Returns list of dashboard filenames and titles for the Reveal viewer dropdown.

Note: the exact route prefixes are registered in Program.cs via Map* endpoints and controllers.

Configuration

• server/aspnet/appsettings.json and appsettings.Development.json contain server configuration such as Reveal SDK and database settings. Edit them to point to your DB and adjust server options.
• server/aspnet/Configuration/ServerOptions.cs defines server options used by the app.

Security & validation notes

• QueryService.GenerateAndSaveQueryAsync sanitizes and validates selected field names and limits the generated SQL length to prevent overly long queries.
• The server registers an AuthenticationProvider and UserContextProvider for Reveal integration — extend or replace these for real authentication.

Developer notes

• To add support for a new data source, register it in Program.cs using the Reveal SDK data source registration helpers, and implement metadata access in DatabaseService.
• Query metadata is stored as JSON with column metadata — this makes it easy to migrate or transform queries later.
