This is an ongoing project which covers two-fold:
- Reverse Engineering Lego Creator Knight's Kingdom
- Modernize the game (using same or similar assets) while expanding functionality
- Superscape VRT 5.71 SDK
- LEGO Creator: Knights Kingdom (2000)
- LEGO Creator: Harry Potter - North American (Windows PC)
- Superscape Do3D Evaluation Version 5.10
- Lego Creator 1998 Lego Group Superscape CD
- Superscape Visualiser
- Superscape Do 3D (1998)
- Superscape VRT v5.60 (1998)
- Superscape Viscape Universal v5.61
Below you will find the associated folders pertaining to the project and research as to which I have gathered on the subject.
For reverse engineering the model data, resources is the place to be.
For writing the modern app, src is the place to be.
This folder contains the files which I have acquired from original developers at Superscape.
Contains certain files which were found in older Superscape VRT 5.71, and used to import data.
Contains sample model file data, with thumbnail, which you can open in any Hex editor to see the finer details.
Python scripts as swell as the MFC42 file which would have been utilized in 2000 to create the game.
Contains the SDK which was documented and used by Superscape employees, to help them understand what the program does.
Here is the compiled research I, along with help from RE community members, have been able to come up with:
This is what the VRT file name consists of, and will let you know the offsets of the VCA files.
This is the Shape data, which you can see follows along with the offsets.
This is the palette data, which also follows along the offsets.
This is the world data, which follows the offsets.
This is a basic brick, with the shape offset at top
Here is an example of the point data which VRT uses. The data is split by memory address in geometric, or regular. Also can have facets and line data as well.
This is what an example script looks like when pulling from VRT 5.60. They updated a ton of new information and features with 5.71, though the developers I talked to did not have copies as the company was bought twice, now owned by EA.
Here is an example of the modified VCA file. I simply added one new point and you can see the difference the HEX file saves it as.
Consists of LCA (24 or 27 bit wrapper over VCA file format containing model data).
The offsets for each subfile such as SHP, PAL, WRLD, etc. are included within this particular file.
Contains the main components which are utilized to recreate and expand upon the game
Contains the upscaled images which I extracted from original bitmaps parsed out to better be utilized later on.
Is a model that I extracted from Lego Island 2, to help get a basic grasp for dealing with the engine/app to utilize. Was becoming worn down and wanted to have some progress to boost my mental health.
Is where the components for each screen will be, to help make workflow of the game easier to utilize. As of now, just recreating with higher definition files, but later on will change things around to be more graphic-oriented like using shaders instead of photos, or real-time rendered scenes. Once the castle data can be extracted will make it into a dynamic not static welcome screen.
